WAGO 231308037000 8-pole Female Plug Connector
The WAGO 231-308/037-000 is a versatile 8-pole female plug connector within the Multi Connection System (MCS). It utilizes WAGO’s innovative CAGE CLAMP® connection technology, enabling easy and secure connection of various conductor types, including solid, stranded, and ferruled conductors. The integrated test ports simplify troubleshooting and maintenance. Designed for applications requiring robust and reliable power distribution, this connector is suitable for industrial automation, control panels, and machinery.
WAGO 231308037000 8-pole Female Plug Connector Specifications:
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 16 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1.5 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 2.5 mm²
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- No. of poles: 8
- Total number of connection points: 8
- Total number of potentials: 8
- Pin spacing: 5.08 mm / 0.2 inch
- Width: 57.24 mm / 2.254 inch
- Height: 14.3 mm / 0.563 inch
- Depth: 29.6 mm / 1.165 inch
- Contact type: Female connector/socket
- Locking of plug-in connection: locking lever
- Color: orange
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Copper alloy
- Contact plating: tin-plated
- Fire load: 0.251 MJ
- Weight: 16.1 g
- Limit temperature range: -60 … +85 °C
