WAGO 769615002000 1-conductor male connector
The WAGO 769-615/002-000 is a 15-pole male connector designed for conductor connections using the innovative CAGE CLAMP® technology. This connector offers a secure and reliable connection for conductors, featuring a clamping collar and a 5 mm pin spacing. Constructed from durable Polyamide (PA66), it's suitable for a wide range of industrial applications where robust and dependable electrical connections are essential. It is compatible with various conductor materials and sizes, making it versatile for different wiring needs. The connector's design facilitates front-entry wiring and is ideal for use in control cabinets and automation systems.
WAGO 769615002000 1-conductor male connector Specifications:
- Nominal Voltage (III/3): 500 V
- Rated Surge Voltage (III/3): 6 kV
- Rated Current: 32 A
- Connection Technology: CAGE CLAMP®
- Actuation Type: Operating tool
- Connectable Conductor Materials: Copper
- Nominal Cross-section: 4 mm²
- Solid Conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Fine-stranded Conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Strip Length: 8 … 9 mm / 0.31 … 0.35 inch
- Pole No.: 15
- Total Number of Connection Points: 15
- Total Number of Potentials: 15
- Wiring Type: Front-entry wiring
- Pin Spacing: 5 mm / 0.197 inch
- Width: 90.4 mm / 3.559 inch
- Height from the Surface: 18.3 mm / 0.72 inch
- Depth: 40.2 mm / 1.583 inch
- Mounting Type: Mounting flange
- Plug-in Connection: Yes
- Contact Type (pluggable connector): Male connector/plug
- Connector (connection type): for conductor
- Color: gray
- Insulation Material: Polyamide (PA66)
- Fire Load: 0.891 MJ
- Weight: 44.4 g
- Product Group: 18 (X-COM-System)
- Packaging Type: BOX
- Country of Origin: PL
- GTIN: 4044918521895
- Customs Tariff Number: 85366990990
