WAGO 231268001000 8 Pole Header Connector
The WAGO 231-268/001-000 is an 8-pole header connector designed for robust and reliable connections in industrial environments. It features straight solder pins with dimensions of 1.2 x 1.2 mm and a pin spacing of 7.5 mm. The connector's closed end and perpendicular mating direction to the PCB ensure secure and efficient integration into various systems. It is suitable for applications requiring a compact and durable connection solution, commonly used in control cabinets, automation systems, and power distribution.
WAGO 231268001000 8 Pole Header Connector Specifications:
- Product Description: HEADER; STRAIGHT SOLDER PIN, 1.2 X 1.2 MM /0.047 X 0.047 IN; 8 POLE; PIN SPACING 7.5 MM / 0.295 IN; WITH CLOSED END; MATING DIRECTION PERPENDICULAR TO PCB
- Packing Unit: 50 pieces
- Product Group: 3 (Multi Conn. System)
- Pin Spacing: 7.5 mm / 0.295 in
- Pole Count: 8
- Measured Voltage EN: 400 V
- Measured Shock Voltage: 6 kV
- Pollution Degree: 3
- Current Intensity EN: 16 A
- Weight: 3.77 g
- Color: grey
- Height: 12 mm / 0.472 in
- Width: 60.5 mm / 2.382 in
- Depth: 8.4 mm / 0.331 in
- Admission Office ABS: 04-HG469925-PDA
- Voltage ABS: 400 V
- Current ABS: 12 A
- Cross Section ABS: N/A
- Admission Office BV: 11915/A0
- Voltage BV: 400 V
- Current BV: 16 A
- Cross Section BV: 2.5 mm²
- Admission Office CCA: 5764
- Voltage CCA: 400 V
- Current CCA: 16 A
- Cross Section CCA: 1.2x1.2
- Admission Office CSA: 154112-1466354
- Voltage CSA: 300 V
- Current CSA: 15 A
- Cross Section CSA: N/A
- Admission Office DEMKO: 88126
- Voltage DEMKO: 400 V
- Current DEMKO: 12 A
- Cross Section DEMKO: 2.5 mm²
- Admission Office GL: 17296-00HH
- Voltage GL: 400 V
- Current GL: 12 A
- Cross Section GL: N/A
- Admission Office KEMA: 2083746.02
- Voltage KEMA: 400 V
- Current KEMA: 16 A
- Cross Section KEMA: 1.2x1.2
- Admission Office LR: 96/20035
- Voltage LR: 400 V
- Current LR: 12 A
- Cross Section LR: N/A
- Admission Office NEMKO: P94101840
- Voltage NEMKO: 400 V
- Current NEMKO: N/A
- Cross Section NEMKO: 2.5 mm²
- Admission Office RMR: 11130002
- Voltage RMR: 400 V
- Current RMR: 12 A
- Cross Section RMR: N/A
- Admission Office UR: E45171
- Voltage UR: 600 V
- Current UR: 15 A
- Cross Section UR: N/A
- Admission Office UR2: E45172
- Voltage UR2: 300 V
- Current UR2: 15 A
- Cross Section UR2: N/A
