WAGO 231304031000 4-pole Female Plug Connector
The WAGO 231-304/031-000 is a 4-pole female plug connector designed for versatile applications within electrical systems. Utilizing WAGO’s innovative CAGE CLAMP technology, it enables both easy cable pre-assembly and on-unit wiring. The integrated test ports simplify troubleshooting and maintenance. This connector is suitable for a wide range of conductor types and offers a secure, reliable connection for various industrial and commercial applications. It is designed to be used within the MULTI CONNECTION SYSTEM (MCS) and should not be connected/disconnected when live or under load.
WAGO 231304031000 4-pole Female Plug Connector Specifications:
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 16 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1.5 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 2.5 mm²
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- No. of poles: 4
- Total number of connection points: 4
- Total number of potentials: 4
- Pin spacing: 5.08 mm / 0.2 inch
- Width: 35.12 mm / 1.383 inch
- Height: 14.3 mm / 0.563 inch
- Depth: 26.45 mm / 1.041 inch
- Mounting type: Mounting flange
- Contact type (pluggable connector): Female connector/socket
- Material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Weight: 8.2 g
- Limit temperature range: -60 … +85 °C
