WAGO 231316026000 16 Pole Female Plug Connector
The WAGO 231-316/026-000 is a 16-pole female plug connector engineered for demanding industrial environments. It incorporates integrated fixing flanges for secure mounting and utilizes the innovative CAGE CLAMP® connection technology, ensuring reliable and vibration-resistant connections. The connector accommodates a broad range of wire sizes, from 28 AWG to 12 AWG, and supports voltage ratings up to 600V, making it suitable for diverse applications in automation, power distribution, and control systems. Its orange color provides visual distinction and easy identification within complex wiring setups.
WAGO 231316026000 16 Pole Female Plug Connector Specifications:
- Product Description: FEMALE PLUG; 16 POLE; PIN SPACING 5.08 MM / 0.2 IN; WITH INTEGRATED FIXING FLANGES; CAGE CLAMP®CONNECTION; WITH CODIG FINGERS
- Packing Unit: 25 pieces
- Product Group: 3 (Multi Conn. System)
- Pin Spacing: 5.08 mm / 0.2 in
- Pole Count: 16
- Cross Section Range (mm²): 0.08 - 2.5
- Cross Section Range (AWG): 28 - 12 AWG
- Connection Method: CAGE CLAMP®CONNECTION
- Measured Voltage (EN): 250 V
- Measured Shock Voltage: 4 kV
- Pollution Degree: 3
- Current Intensity (EN): 16 A
- Weight: 29.4 g
- Color: orange
- Number of Connection Points: 16
- Number of Potentials: 16
- Height: 14.3 mm / 0.563 in
- Width: 82.78 mm / 3.259 in
- Depth: 26.45 mm / 1.041 in
- Strip Length: 8 - 9 mm / 0.33 in
- BV Approval No.: 11915/A0
- CCA Approval: 5764
- CSA Approval: 154112-1466354
- DEMKO Approval: 88126
- KEMA Approval: 2083746.02
- KR Approval: HMB05880-EL003
- NEMKO Approval: P94101840
- UR Approval: E45171
- UR Approval 2: E45172
Buy the 231-316/026-000 WAGO 16 Pole Female Plug Connector | myMectronic
Purchase the WAGO 231-316/026-000 securely and efficiently through our online platform.
Buy Now
Frequently Asked Questions
Where can I buy WAGO 231316026000?
You can click on the BUY or RFQ button to purchase 231316026000 from an authorized WAGO distributor.
How do I troubleshoot issues or seek technical support for part 231316026000?
You can download the 231316026000 datasheet or visit the WAGO website for support.
Who is the manufacturer of 231316026000?
WAGO
