WAGO 231364001000 Straight Solder Pin Connector
The WAGO 231-364/001-000 is a robust, 4-pole straight solder pin connector ideal for connecting to PCBs. It offers a 5.08mm pin spacing and a closed end design. This connector is suitable for a wide range of applications requiring reliable connections in industrial environments, and is approved by numerous agencies including ABS, BV, and UL. It is designed for perpendicular PCB mounting and offers a secure and efficient connection solution.
Authorized Distributors
Source:Master Electronics
Part No:231-364/001-000
Stock:360
Inv Date:06-04-2026
Price: Unit price: $1.94
Buy/RFQ:
Source:Onlinecomponents.com
Part No:231-364/001-000
Stock:360
Inv Date:06-04-2026
Price: Unit price: $1.94
Buy/RFQ:
Source:Future Electronics Corporate
Part No:231-364/001-000
Stock:0
Inv Date:06-04-2026
Price: Unit price: $1.59
Buy/RFQ:
WAGO 231364001000 Straight Solder Pin Connector Specifications:
- Product Description: Straight solder pin, 1.2 x 1.2 mm / 0.047 x 0.047 in, 4 pole, pin spacing 5.08 mm / 0.2 in, mating direction perpendicular to PCB, with closed end
- Packing Unit: 200 (4*50 pieces)
- Product Group: 3 (Multi Conn. System)
- Pin Spacing: 5.08 mm / 0.2 in
- Pole Count: 4
- Measured Voltage: 250 V
- Measured Shock Voltage: 4 kV
- Pollution Degree: 3
- Current Intensity: 16 A
- Weight: 1.692 g
- Color: orange
- Height: 12 mm / 0.472 in
- Width: 23.52 mm / 0.926 in
- Depth: 8.4 mm / 0.331 in
- Cross Section: 0.8-2.5 mm²
- Voltage: 400 V
- Current: 12-16 A
- Approval ABS: 04-HG469925-PDA
- Approval BV: 11915/A0
- Approval CCA: 5764
- Approval CSA: 154112-1466354
- Approval DEMKO: 88126
- Approval GL: 17296-00HH
- Approval KEMA: 2083746.02
- Approval KR: HMB05880-EL003
- Approval LR: 96/20035
- Approval NEMKO: P94101840
- Approval RMR: 11130002
- Approval UR: E45171
- Approval UR2: E45172
