WAGO 231462001000 Right Angle Solder Pin Header
The WAGO 231-462/001-000 is a 2-pole right-angle solder pin header, part of WAGO's multi-connection system. Designed for parallel PCB mating, this header offers a compact and efficient solution for connecting components. It features a 5mm pin spacing, a closed end, and is suitable for a wide range of industrial applications where reliable and space-saving connections are required. The header is rated for a measured voltage of 250V and a current intensity of 16A, ensuring robust performance in demanding environments. It is also compliant with various industry standards and approvals, including ABS, BV, and UL.
WAGO 231462001000 Right Angle Solder Pin Header Specifications:
- product_description: HEADER; RIGHT ANGLE SOLDER PIN, 1.2 X 1.2 MM/ 0.047 X 0.047 IN; 2 POLE; PIN SPACING 5 MM / 0.197 IN; MATING DIRECTION PARALLEL TO PCB; WITH CLOSED END
- packing_unit: 200 (4*50 pieces)
- product_group: 3 (Multi Conn. System)
- pin_spacing: 5 mm / 0.197 in
- pole_count: 2
- measured_voltage_en: 250 V
- measured_shock_voltage: 4 kV
- pollution_degree: 3
- current_intensity_en: 16 A
- weight: 0,953 g
- color: grey
- height: 8,4 mm / 0,331 in
- width: 13,2 mm / 0,52 in
- depth: 12 mm / 0,472 in
- admission_office_abs: 04-HG469925-PDA
- approval_no_bv: 11915/A0
- voltage_bv: 400 V
- current_bv: 16 A
- cross_section_abs: 5,0 mm²
- approval_no_cca: 5764
- voltage_cca: 250 V
- current_cca: 16 A
- cross_section_cca: 1,2x,21 mm²
- approval_no_csa: 154112-1466354
- voltage_csa: 300 V
- current_csa: 15 A
- approval_no_demko: 88126
- voltage_demko: 250 V
- current_demko: N/A
- cross_section_demko: 2,5 mm²
- approval_no_gl: 17296-00HH
- voltage_gl: 400 V
- current_gl: 16 A
- approval_no_kema: 2083746.02
- voltage_kema: 250 V
- current_kema: 16 A
- cross_section_kema: 1,2x,21 mm²
- approval_no_kr: HMB05880-EL003
- voltage_kr: 250/400 V
- current_kr: 12/16 A
- cross_section_kr: 2,5 mm²
- approval_no_lr: 96/20035
- voltage_lr: 400 V
- current_lr: 16 A
- approval_no_nemko: P94101840
- voltage_nemko: 250 V
- approval_no_rmr: 11130002
- voltage_rmr: 400 V
- current_rmr: 16 A
- approval_no_ur: E45171
- voltage_ur_1: 600 V
- current_ur_1: 15 A
- approval_no_ur_2: E45172
- voltage_ur_2: 300 V
- current_ur_2: 15 A
