WAGO 231603019000 3-pole Connector
The WAGO 231-603/019-000 is a 3-pole male connector designed for universal conductor types. It utilizes WAGO’s CAGE CLAMP® connection technology for easy cable pre-assembly and on-unit wiring, supporting both vertical and horizontal actuation. This connector is suitable for wire-to-wire and board-to-wire connections and is available with snap-in mounting feet or flanges for flexible panel mounting. It is rated for various voltages and currents and complies with several industry standards, making it a reliable choice for diverse industrial applications.
WAGO 231603019000 3-pole Connector Specifications:
- conductor_size: 2.5 mm²
- pin_spacing: 5 mm
- number_of_poles: 3
- color: gray
- mounting_type: Mounting flange, Feed-through mounting, Panel mounting
- voltage_iii_3: 320 V
- surge_voltage_iii_3: 4 kV
- voltage_ii_2: 630 V
- surge_voltage_ii_2: 4 kV
- rated_current: 12 A
- rated_voltage_ul_use_group_b: 300 V
- rated_current_ul_use_group_b: 15 A
- rated_voltage_ul_use_group_d: 300 V
- rated_current_ul_use_group_d: 10 A
- rated_voltage_ul_1977: 600 V
- rated_current_ul_1977: 15 A
- rated_voltage_csa_use_group_b: 300 V
- rated_current_csa_use_group_b: 15 A
- rated_voltage_csa_use_group_d: 300 V
- rated_current_csa_use_group_d: 10 A
- connection_technology: CAGE CLAMP®
- solid_conductor_size: 0.08 … 2.5 mm² / 28 … 12 AWG
- fine_stranded_conductor_size: 0.08 … 2.5 mm² / 28 … 12 AWG
- fine_stranded_conductor_ferrule_size: 0.25 … 1.5 mm²
- fine_stranded_conductor_uninsulated_ferrule_size: 0.25 … 2.5 mm²
- strip_length: 8 … 9 mm / 0.31 … 0.35 inch
- total_number_of_connection_points: 3
- total_number_of_potentials: 3
- number_of_connection_types: 1
- number_of_levels: 1
- conductor_entry_direction: 0 °
- width: 29.8 mm / 1.173 inch
- height: 14.3 mm / 0.563 inch
- depth: 27.5 mm / 1.083 inch
- flammability_class_ul94: V0
- material_group: I
- insulation_material: Polyamide (PA66)
- clamping_spring_material: Chrome nickel spring steel (CrNi)
- contact_material: Electrolytic copper (E Cu)
- contact_plating: tin-plated
- fire_load: 0.114 MJ
- weight: 5.8 g
- limit_temperature_range: -60 … +100 °C
