WAGO 231634019000 4-pole Connector
The WAGO 231-634/019-000 is a robust 4-pole male connector designed for reliable connections in various industrial settings. Its clamping collar and CAGE CLAMP® actuation facilitate easy cable pre-assembly and on-unit wiring. This connector supports a wide range of conductor types and sizes, making it suitable for wire-to-wire and board-to-wire connections. Versions are available with snap-in mounting feet or flanges for flexible panel integration. It is designed without breaking capacity for compliance with DIN EN 61984 and is ideal for applications requiring secure and efficient power distribution.
WAGO 231634019000 4-pole Connector Specifications:
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 12 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1.5 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 2.5 mm²
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- No. of poles: 4
- Total number of connection points: 4
- Total number of potentials: 4
- Pin spacing: 5.08 mm / 0.2 inch
- Width: 35.12 mm / 1.383 inch
- Height: 14.3 mm / 0.563 inch
- Depth: 27.5 mm / 1.083 inch
- Mounting type: Mounting flange
- Contact type (pluggable connector): Male connector/plug
- Color: orange
- Flammability class per UL94: V0
