WAGO 231634114000 4-pole Connector
The WAGO 231-634/114-000 is a 4-pole connector within the MCS – MULTI CONNECTION SYSTEM, ideal for wire-to-wire and board-to-wire connections. It offers easy cable pre-assembly and on-unit wiring through vertical and horizontal CAGE CLAMP actuation. The connector is designed with a snap-in flange for secure mounting and is suitable for a wide range of industrial applications where reliable and efficient connections are required. It is important to note that this connector does not have breaking capacity and should not be connected/disconnected when live or under load.
WAGO 231634114000 4-pole Connector Specifications:
- conductor_type: 1-conductor
- pin_spacing: 5.08 mm
- pole_number: 4
- conductor_size: 2.5 mm²
- color: orange
- actuation_type: Operating tool
- solid_conductor_size: 0.08 … 2.5 mm² / 28 … 12 AWG
- fine_stranded_conductor_size: 0.08 … 2.5 mm² / 28 … 12 AWG
- ferruled_fine_stranded_conductor_size: 0.25 … 1.5 mm²
- unferruled_fine_stranded_conductor_size: 0.25 … 2.5 mm²
- strip_length: 8 … 9 mm / 0.31 … 0.35 inch
- total_connection_points: 4
- total_potentials: 4
- number_of_connection_types: 1
- number_of_levels: 1
- conductor_entry_direction: 0 °
- nominal_voltage_iii3: 320 V
- rated_surge_voltage_iii3: 4 kV
- rated_voltage_iii2: 320 V
- rated_surge_voltage_iii2: 4 kV
- nominal_voltage_ii2: 630 V
- rated_surge_voltage_ii2: 4 kV
- rated_current: 12 A
- rated_voltage_ul_use_group_b: 300 V
- rated_current_ul_use_group_b: 15 A
- rated_voltage_ul_use_group_d: 300 V
- rated_current_ul_use_group_d: 10 A
- rated_voltage_ul_1977: 600 V
- rated_current_ul_1977: 15 A
- rated_voltage_csa_use_group_b: 300 V
- rated_current_csa_use_group_b: 15 A
- rated_voltage_csa_use_group_d: 300 V
- rated_current_csa_use_group_d: 10 A
- housing_sheet_thickness: 0.5 … 2.5 mm / 0.02 … 0.098 inch
- mounting_type: Snap-in
- feedthrough_mounting: Feed-through mounting
- contact_type: Male connector/plug
- mismating_protection: No
- insulation_material: Polyamide 66 (PA 66)
- clamping_spring_material: Chrome nickel spring steel (CrNi)
- contact_material: Electrolytic copper (E Cu)
- contact_plating: tin-plated
- fire_load: 0.173 MJ
- weight: 8.6 g
- limit_temperature_range: -60 … +100 °C
- packaging_type: BOX
- country_of_origin: DE
- gtin: 4050821279761
- customs_tariff_number: 85366990990
