WAGO 231742001000 12 Pole Header
The WAGO 231-742/001-000 is a robust 12-pole THT (Through-Hole Technology) male header designed for secure and reliable PCB connections. It features a 7.62mm pin spacing, facilitating easy integration into a variety of circuit board designs. The header's orange housing provides clear visual identification. It is suitable for applications requiring secure connections in industrial automation, control systems, and power distribution panels. The header is RoHS compliant, ensuring environmental responsibility. It is designed for horizontal or vertical PCB mounting and offers coding fingers for enhanced assembly and error prevention.
WAGO 231742001000 12 Pole Header Specifications:
- Pin Spacing: 7.62 mm
- Number of Poles: 12
- Pin Cross-section: 1 x 1 mm
- Width: 92.02 mm
- Height: 17 mm
- Height from Surface: 12 mm
- Depth: 8.4 mm
- Solder Pin Length: 5 mm
- Drilled Hole Diameter: 1.4 mm
- Nominal Voltage (III/3): 500 V
- Rated Surge Voltage (III/3): 6 kV
- Rated Voltage (III/2): 630 V
- Rated Current: 12 A
- Rated Voltage UL (Use Group B): 300 V
- Rated Current UL (Use Group B): 10 A
- Material: Polyamide 66 (PA 66)
- Flammability Class: V0
- Contact Material: Electrolytic Copper (E Cu)
- Contact Plating: Tin-plated
- Color: orange
- Packaging Type: BOX
- Country of Origin: PL
Buy the 231-742/001-000 WAGO 12 Pole Header | myMectronic
Purchase the WAGO 231-742/001-000 THT male header securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy WAGO 231742001000?
You can click on the BUY or RFQ button to purchase 231742001000 from an authorized WAGO distributor.
How do I troubleshoot issues or seek technical support for part 231742001000?
You can download the 231742001000 datasheet or visit the WAGO website for support.
Who is the manufacturer of 231742001000?
WAGO
