WAGO 232132 2-pole Female Header
The WAGO 232-132 is a 2-pole female header designed for reliable PCB connections. It offers horizontal or vertical mounting options via straight solder pins and is ideal for board-to-board and board-to-wire applications. The touch-proof PCB outputs enhance safety, while coding fingers simplify identification. This header is rated for 320V and 12A, and is certified by UL, CSA, and KEMA, ensuring compliance with industry standards. It's a versatile solution for various industrial applications requiring secure and efficient electrical connections.
WAGO 232132 2-pole Female Header Specifications:
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 12 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Total number of potentials: 2
- Number of connection types: 1
- Number of levels: 1
- No. of poles: 2
- Pin spacing: 5 mm / 0.197 inch
- Width: 11.5 mm / 0.453 inch
- Height: 23.25 mm / 0.915 inch
- Height from the surface: 18.25 mm / 0.719 inch
- Depth: 11.6 mm / 0.457 inch
- Solder pin length: 5 mm
- Solder pin dimensions: 0.6 x 1 mm
- Drilled hole diameter (tolerance): 1.3 mm (- … +0.1)
- Contact type (pluggable connector): Female connector/socket
- Connector connection type: for PCBs
- Mismating protection: No
- Mating direction to the PCB: 90 °
- PCB contact: THT
- Solder pin arrangement: over the entire female connector, in line
- Number of solder pins per potential: 1
- Color: gray
- Material group: I
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Contact material: Copper alloy
- Contact plating: tin-plated
- Fire load: 0.036 MJ
- Weight: 1.956 g
- Limit temperature range: -60 … +85 °C
- Product Group: 3 (Multi Conn. System)
- Country of origin: DE
- GTIN: 4044918578264
- Customs Tariff No.: 85366990990
