WAGO 232172 THT Female Header Connector
The WAGO 232-172 THT female header connector is a versatile component for connecting PCBs and wires. Designed with a 5.08mm pin spacing and 12 poles, it facilitates secure and reliable connections in various industrial applications. The connector's straight solder pins allow for horizontal or vertical PCB mounting, while touch-proof outputs enhance safety. Coding fingers simplify identification, and the robust polyamide 66 construction ensures durability. It is suitable for board-to-board and board-to-wire connections, making it ideal for a wide range of electronic devices and systems.
WAGO 232172 THT Female Header Connector Specifications:
- Pin spacing: 5.08 mm / 0.2 inch
- Width: 62.46 mm / 2.459 inch
- Height: 23.25 mm / 0.915 inch
- Height from the surface: 18.25 mm / 0.719 inch
- Depth: 11.6 mm / 0.457 inch
- Solder pin length: 5 mm
- Solder pin dimensions: 0.6 x 1 mm
- Drilled hole diameter (tolerance): 1.3 mm (- … +0.1)
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 12 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- No. of poles: 12
- Total number of connection points: 12
- Total number of potentials: 12
- Number of connection types: 1
- Number of levels: 1
- Contact type (pluggable connector): Female connector/socket
- Connector connection type: for PCBs
- Mismating protection: No
- Mating direction to the PCB: 90 °
- Color: orange
- Material group: I
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Contact material: Copper alloy
- Contact plating: tin-plated
- Fire load: 0.173 MJ
- Weight: 10.4 g
- Limit temperature range: -60 … +85 °C
