WAGO 250102 2-pole PCB Terminal Block
The WAGO 250-102 is a compact, 2-pole PCB terminal block designed for efficient and reliable connections in various industrial applications. Its push-button CAGE CLAMP® connection technology allows for quick and easy termination of both solid and stranded conductors, simplifying the wiring process. The 3.5mm pin spacing optimizes space utilization on printed circuit boards. This terminal block is suitable for applications requiring robust and secure connections, such as automation systems, power distribution, and control panels. It is designed to meet the demands of modern industrial environments, offering a combination of ease of use, reliability, and compact size.
WAGO 250102 2-pole PCB Terminal Block Specifications:
- Rated Voltage (III/3): 160 V
- Rated Surge Voltage (III/3): 2.5 kV
- Rated Voltage (III/2): 160 V
- Rated Surge Voltage (III/2): 2.5 kV
- Rated Voltage (II/2): 320 V
- Rated Surge Voltage (II/2): 2.5 kV
- Rated Current: 8 A
- Pin Spacing: 3.5 mm
- Number of Poles: 2
- Conductor Size (Solid): 0.2 … 1.5 mm² / 24 … 16 AWG
- Conductor Size (Stranded): 0.2 … 1.5 mm² / 24 … 16 AWG
- Conductor Size (Ferruled): 0.25 … 1 mm²
- Strip Length: 8.5 … 9.5 mm
- Conductor Connection Direction: 45 °
- Width: 8.5 mm
- Height: 16.7 mm
- Depth: 12 mm
- Solder Pin Length: 3.6 mm
- Solder Pin Dimensions: 0.4 x 0.75 mm
- Material (Insulation): Polyamide 66 (PA66)
- Flammability Rating: V0
- Weight: 1.1 g
- Operating Temperature Range: -60 … +105 °C
- Customs Tariff Number: 85369010000
