WAGO 26243104 4mm PCB Terminal Block
The WAGO 2624-3104 is a robust and reliable PCB terminal block ideal for various industrial applications, particularly panel feedthrough scenarios. Its Push-in CAGE CLAMP connection simplifies conductor termination, accommodating both solid and ferruled conductors. The block is rated for a nominal voltage of 320V and a rated current of 41A, ensuring safe and efficient power transmission. It is also certified by UL, CSA, and KEMA, demonstrating its adherence to stringent quality and safety standards. The terminal block's compact design and easy-to-use features make it a valuable component in a wide range of electrical systems.
WAGO 26243104 4mm PCB Terminal Block Specifications:
- Nominal Voltage (III/3): 320 V
- Rated Surge Voltage (III/3): 4 kV
- Nominal Voltage (III/2): 400 V
- Rated Surge Voltage (III/2): 4 kV
- Nominal Voltage (II/2): 630 V
- Rated Surge Voltage (II/2): 4 kV
- Rated Current: 41 A
- Rated Voltage UL (Use Group B): 300 V
- Rated Current UL (Use Group B): 26 A
- Rated Voltage UL (Use Group D): 300 V
- Rated Current UL (Use Group D): 10 A
- Rated Voltage CSA (Use Group B): 300 V
- Rated Current CSA (Use Group B): 26 A
- Rated Voltage CSA (Use Group D): 300 V
- Rated Current CSA (Use Group D): 5 A
- Connection Technology: Push-in CAGE CLAMP®
- Solid Conductor Size: 0.2 … 6 mm² / 24 … 10 AWG
- Fine-Stranded Conductor Size: 0.2 … 6 mm² / 24 … 10 AWG
- Fine-Stranded Conductor w/ Insulated Ferrule Size: 0.25 … 2.5 mm²
- Fine-Stranded Conductor w/ Uninsulated Ferrule Size: 0.25 … 2.5 mm²
- Fine-Stranded Conductor w/ Twin Ferrule Size: 0.25 … 1.5 mm²
- Strip Length: 10 … 12 mm / 0.39 … 0.47 inch
- Conductor Connection Direction to PCB: 90 °
- Pole No.: 4
- Total Number of Connection Points: 4
- Total Number of Potentials: 4
- Number of Connection Types: 1
- Number of Levels: 1
- Pin Spacing: 5 mm / 0.197 inch
- Width: 21.5 mm / 0.846 inch
- Height: 20.3 mm / 0.799 inch
- Height from Surface: 16.3 mm / 0.642 inch
- Depth: 15.4 mm / 0.606 inch
- Solder Pin Length: 4 mm
- Solder Pin Dimensions: 0.8 x 1 mm
- Drilled Hole Diameter (Tolerance): 1.3 (+0.1) mm
- Material Group: I
- Insulation Material: Polyamide (PA66)
- Flammability Class per UL94: V0
- Clamping Spring Material: Chrome nickel spring steel (CrNi)
- Contact Material: Electrolytic copper (E) Cu
- Contact Plating: tin-plated
- Weight: 6.6 g
- Limit Temperature Range: -60 … +105 °C
- Country of Origin: DE
- GTIN: 4055143578769
- Customs Tariff Number: 85369010000
