WAGO 26261102020000 2-pole PCB Terminal Block
The WAGO 2626-1102/020-000 is a robust 2-pole PCB terminal block designed for reliable electrical connections in a variety of industrial applications. Utilizing the innovative Push-in CAGE CLAMP® connection, it allows for quick and secure termination of both solid and ferruled conductors. The 7.5mm pin spacing facilitates efficient layout design, and its compact form factor makes it ideal for space-constrained environments. This terminal block is suitable for panel feedthrough applications and offers convenient testing capabilities. It is rated for high voltage and current, ensuring dependable performance in demanding electrical systems.
WAGO 26261102020000 2-pole PCB Terminal Block Specifications:
- Nominal Voltage (III/3): 800 V
- Rated Surge Voltage (III/3): 8 kV
- Rated Voltage (III/2): 1000 V
- Rated Surge Voltage (III/2): 8 kV
- Rated Voltage (II/2): 1000 V
- Rated Surge Voltage (II/2): 8 kV
- Rated Current: 48 A
- Rated Voltage UL (Use Group B): 600 V
- Rated Current UL (Use Group B): 38 A
- Rated Voltage UL (Use Group C): 600 V
- Rated Current UL (Use Group C): 38 A
- Rated Voltage CSA (Use Group B): 600 V
- Rated Current CSA (Use Group B): 38 A
- Rated Voltage CSA (Use Group C): 600 V
- Rated Current CSA (Use Group C): 38 A
- Connection Technology: Push-in CAGE CLAMP®
- Solid Conductor Range: 0.2 … 10 mm² / 24 … 8 AWG
- Fine-Stranded Conductor Range: 0.2 … 10 mm² / 24 … 8 AWG
- Fine-Stranded Conductor w/ Insulated Ferrule Range: 0.25 … 6 mm²
- Fine-Stranded Conductor w/ Uninsulated Ferrule Range: 0.25 … 6 mm²
- Fine-Stranded Conductor w/ Twin Ferrule Range: 0.25 … 2.5 mm²
- Strip Length: 13 … 15 mm / 0.51 … 0.59 inch
- Pin Spacing: 7.5 mm / 0.295 inch
- Width: 16.8 mm / 0.661 inch
- Height: 23.6 mm / 0.929 inch
- Height from Surface: 19.6 mm / 0.772 inch
- Depth: 24.2 mm / 0.953 inch
- Solder Pin Length: 4 mm
- Solder Pin Dimensions: 1.5 x 1 mm
- Drilled Hole Diameter: 2 mm (+0.1)
- Material Group: I
- Insulation Material: Polyamide (PA66)
- Flammability Class UL94: V0
- Clamping Spring Material: Chrome nickel spring steel (CrNi)
- Contact Material: Electrolytic copper (E) Cu
- Contact Plating: tin-plated
- Weight: 8.2 g
- Limit Temperature Range: -60 … +105 °C
- Packaging Type: BOX
- Country of Origin: DE
- GTIN: 4055143587075
- Customs Tariff Number: 85369010000
