WAGO 2721111037000 11-pole Female Connector
The WAGO 2721-111/037-000 is a versatile 11-pole female connector within the MCS – MULTI CONNECTION SYSTEM. It's designed for universal conductor compatibility and simplifies wiring with its push-in CAGE CLAMP technology. The connector's robust design includes a locking lever and 100% protection against mismating, ensuring reliable connections in industrial applications. It's suitable for various applications requiring secure and efficient conductor termination, and is UL and CSA approved.
WAGO 2721111037000 11-pole Female Connector Specifications:
- Material Group: I
- Insulation Material: Polyamide (PA66)
- Flammability Class UL94: V0
- Clamping Spring Material: Chrome nickel spring steel (CrNi)
- Contact Material: Copper alloy
- Contact Plating: tin-plated
- Nominal Voltage (III/3): 320 V
- Rated Surge Voltage (III/3): 4 kV
- Rated Voltage (III/2): 320 V
- Rated Surge Voltage (III/2): 4 kV
- Nominal Voltage (II/2): 630 V
- Rated Surge Voltage (II/2): 4 kV
- Rated Current: 16 A
- Rated Voltage UL (Use Group B): 300 V
- Rated Current UL (Use Group B): 15 A
- Rated Voltage UL (Use Group C): 150 V
- Rated Current UL (Use Group C): 15 A
- Rated Voltage UL (Use Group D): 300 V
- Rated Current UL (Use Group D): 10 A
- Rated Voltage UL 1977: 600 V
- Rated Current UL 1977: 15 A
- Rated Voltage CSA (Use Group B): 300 V
- Rated Current CSA (Use Group B): 15 A
- Rated Voltage CSA (Use Group C): 300 V
- Rated Current CSA (Use Group C): 15 A
- Rated Voltage CSA (Use Group D): 300 V
- Rated Current CSA (Use Group D): 10 A
- Connection Technology: Push-in CAGE CLAMP®
- Solid Conductor: 0.2 … 2.5 mm² / 24 … 12 AWG
- Fine-Stranded Conductor: 0.2 … 2.5 mm² / 24 … 12 AWG
- Fine-Stranded Conductor with Insulated Ferrule: 0.25 … 1.5 mm²
- Fine-Stranded Conductor with Uninsulated Ferrule: 0.25 … 2.5 mm²
- Strip Length: 10 … 11 mm / 0.39 … 0.43 inch
- Pole No.: 11
- Total Number of Connection Points: 11
- Total Number of Potentials: 11
- Number of Connection Types: 1
- Number of Levels: 1
- Conductor Entry Direction to Mating Direction: 0 °
- Pin Spacing: 5 mm / 0.197 inch
- Width: 71.7 mm / 2.823 inch
- Height: 15 mm / 0.591 inch
- Depth: 29.8 mm / 1.173 inch
- Fire Load: 0.373 MJ
- Weight: 18.9 g
- Mismating Protection: Yes
- Locking of Plug-in Connection: locking lever
- Color: light gray
