WAGO 2734108037000 8-pole Female Plug
The WAGO 2734-108/037-000 is an 8-pole female plug connector within the MULTI CONNECTION SYSTEM (MCS). It offers a universal connection solution suitable for all conductor types, simplifying wiring processes and eliminating the need for specialized tools. The integrated push-in CAGE CLAMP® technology ensures reliable and secure connections, while the push-button actuation allows for easy termination of both solid and ferruled conductors. A key feature is the integrated test port, enabling parallel testing of conductors without disrupting the circuit. The design incorporates a locking lever and coding via coding fingers to prevent mismating and ensure proper connection. This connector is ideal for industrial applications requiring robust and efficient wiring solutions.
WAGO 2734108037000 8-pole Female Plug Specifications:
- Rated voltage (III / 3): 160 V
- Rated impulse voltage (III / 3): 2.5 kV
- Rated voltage (III / 2): 160 V
- Rated impulse voltage (III / 2): 2.5 kV
- Rated voltage (II / 2): 320 V
- Rated impulse voltage (II / 2): 2.5 kV
- Rated current: 10 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 10 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 10 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: Push-in CAGE CLAMP®
- Actuation type: Push-button
- Solid conductor: 0.2 … 1.5 mm² / 24 … 16 AWG
- Fine-stranded conductor: 0.2 … 1.5 mm² / 24 … 16 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 0.75 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 1.5 mm²
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- No. of poles: 8
- Total number of connection points: 8
- Total number of potentials: 8
- Number of connection types: 1
- Number of levels: 1
- Conductor entry direction to mating direction: 0 °
- Pin spacing: 3.5 mm / 0.138 inch
- Width: 39 mm / 1.535 inch
- Height: 13.5 mm / 0.531 inch
- Depth: 20.4 mm / 0.803 inch
- Contact type (pluggable connector): Female connector/socket
- Mismating protection: Yes
- Locking of plug-in connection: locking lever
- Color: light gray
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Copper alloy
- Contact plating: tin-plated
- Fire load: 0.148 MJ
- Weight: 7.4 g
- Limit temperature range: -60 … +100 °C
- Product Group: 3 (Multi Conn. System)
- Packaging type: BOX
- Country of origin: PL
- GTIN: 4055143293600
- Customs Tariff No.: 85366990990
