WAGO 231374001000 THT Male Header
The WAGO 231-374/001-000 is a 14-pole THT male header designed for robust PCB connections. Its 5.08mm pin spacing and 1.2 x 1.2mm solder pins provide stability and allow for a nominal current up to 16A. The header is suitable for horizontal or vertical PCB mounting and includes coding fingers for easy identification. It is UL, CSA, and KEMA certified, making it suitable for a wide range of industrial applications. The header is constructed from polyamide 66 (PA 66) with electrolytic copper contacts, tin-plated for corrosion resistance.
WAGO 231374001000 THT Male Header Specifications:
- Rated Voltage (III / 3): 250 V
- Rated Impulse Voltage (III / 3): 4 kV
- Rated Voltage (III / 2): 320 V
- Rated Impulse Voltage (III / 2): 4 kV
- Rated Voltage (II / 2): 630 V
- Rated Impulse Voltage (II / 2): 4 kV
- Rated Current: 16 A
- Pin Spacing: 5.08 mm
- Number of Poles: 14
- Total Number of Potentials: 14
- Solder Pin Length: 5 mm
- Solder Pin Dimensions: 1.2 x 1.2 mm
- Drilled Hole Diameter: 1.7 mm
- Material: Polyamide 66 (PA 66)
- Flammability Class: V0
- Contact Material: Electrolytic Copper (E Cu)
- Contact Plating: Tin-plated
- Color: orange
- Width: 74.24 mm
- Height: 17 mm
- Height from Surface: 12 mm
- Depth: 8.4 mm
- Weight: 5.3 g
- Limit Temperature Range: -60 … +100 °C
- UL Rated Voltage (Use Group B): 300 V
- UL Rated Current (Use Group B): 15 A
- UL Rated Voltage (Use Group D): 300 V
- UL Rated Current (Use Group D): 10 A
- CSA Rated Voltage (Use Group B): 300 V
- CSA Rated Current (Use Group B): 15 A
- CSA Rated Voltage (Use Group D): 300 V
- CSA Rated Current (Use Group D): 10 A
