WAGO 721112027000 12-pole Female Connector
The WAGO 721-112/027-000 is a 12-pole female connector within the MCS – MULTI CONNECTION SYSTEM. It offers universal compatibility for all conductor types and simplifies wiring with its CAGE CLAMP actuation. The connector is 100% protected against mismating and includes integrated test ports. It is suitable for various industrial applications requiring reliable and secure electrical connections.
Authorized Distributors
Source:Master Electronics
Part No:721-112/027-000
Stock:5
Inv Date:06-04-2026
Price: Unit price: $18.03
Buy/RFQ:
Source:Onlinecomponents.com
Part No:721-112/027-000
Stock:5
Inv Date:06-04-2026
Price: Unit price: $18.03
Buy/RFQ:
WAGO 721112027000 12-pole Female Connector Specifications:
- conductor_size: 0.08 … 2.5 mm² / 28 … 12 AWG
- fine_stranded_conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- ferruled_conductor: 0.25 … 1.5 mm² (insulated), 0.25 … 2.5 mm² (uninsulated)
- strip_length: 8 … 9 mm / 0.31 … 0.35 inch
- pole_number: 12
- total_connection_points: 12
- total_potentials: 12
- levels: 1
- conductor_entry_direction: 0 °
- pin_spacing: 5 mm / 0.197 inch
- width: 74.8 mm / 2.945 inch
- height: 14.3 mm / 0.563 inch
- depth: 26.45 mm / 1.041 inch
- mounting_type: Mounting flange, Feed-through mounting, Panel mounting
- contact_type: Female connector/socket
- mismating_protection: Yes
- locking: Without
- insulation_material: Polyamide (PA66)
- flammability_class: V0
- spring_material: Chrome nickel spring steel (CrNi)
- contact_material: Copper alloy
- contact_plating: tin-plated
- fire_load: 0.327 MJ
- weight: 22.9 g
- nominal_voltage_iii3: 320 V
- rated_surge_voltage_iii3: 4 kV
- rated_voltage_iii2: 320 V
- rated_surge_voltage_iii2: 4 kV
- nominal_voltage_ii2: 630 V
- rated_surge_voltage_ii2: 4 kV
- rated_current: 16 A
- rated_voltage_ul_use_b: 300 V
- rated_current_ul_use_b: 15 A
- rated_voltage_ul_use_d: 300 V
- rated_current_ul_use_d: 10 A
- rated_voltage_ul: 600 V
- rated_current_ul: 15 A
- rated_voltage_csa_use_b: 300 V
- rated_current_csa_use_b: 15 A
- rated_voltage_csa_use_d: 300 V
- rated_current_csa_use_d: 10 A
- limit_temperature_range: -60 … +85 °C
- gtin: 4044918355612
- customs_tariff_number: 85366990990
