WAGO 734104107000 4-pole Female Plug Connector
The WAGO 734-104/107-000 is a 4-pole female plug connector designed for versatile applications. Its CAGE CLAMP technology simplifies wiring, allowing for both vertical and horizontal actuation. The 100% mismating protection ensures secure connections, while the screw flange provides added stability. Suitable for a wide range of conductor types and sizes, this connector is ideal for industrial automation, control panels, and power distribution systems. It is designed to be used with compatible male headers for a complete connection solution.
WAGO 734104107000 4-pole Female Plug Connector Specifications:
- Rated voltage (III / 3): 160 V
- Rated impulse voltage (III / 3): 2.5 kV
- Rated voltage (III / 2): 160 V
- Rated impulse voltage (III / 2): 2.5 kV
- Rated voltage (II / 2): 320 V
- Rated impulse voltage (II / 2): 2.5 kV
- Rated current: 10 A
- Solid conductor: 0.08 … 1.5 mm² / 28 … 14 AWG
- Fine-stranded conductor: 0.08 … 1.5 mm² / 28 … 14 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1.5 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 1.5 mm²
- Strip length: 6 … 7 mm / 0.24 … 0.28 inch
- No. of poles: 4
- Total number of connection points: 4
- Total number of potentials: 4
- Pin spacing: 3.5 mm / 0.138 inch
- Width: 23.5 mm / 0.925 inch
- Height: 13.4 mm / 0.528 inch
- Depth: 18.6 mm / 0.732 inch
- Contact type: Female connector/socket
- Mismating protection: Yes
- Locking of plug-in connection: Screw flange
- Color: light gray
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Copper alloy
- Contact plating: tin-plated
- Fire load: 0.062 MJ
- Weight: 4.2 g
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4045454683450
- Customs Tariff No.: 85366990990
