WAGO 734124 Female Connector 24 Pole
The WAGO 734-124 is a robust 24-pole female connector designed for reliable and secure connections in industrial automation and control systems. Featuring a 3.5mm pin spacing and 100% protection against mismating with coding fingers, this connector ensures consistent and error-free connections. The CAGE CLAMP® connection system simplifies wiring and provides a secure hold for conductors ranging from 0.08 to 1.5 mm² (28-14 AWG). It is suitable for applications requiring high voltage and current capacity, with ratings up to 250V and 10A, and approvals including ABS, CCA, CSA, KEMA, and UR.
WAGO 734124 Female Connector 24 Pole Specifications:
- Product Description: FEMALE CONNECTOR 24 POLE PIN SPACING 3.5 MM / 0.138 IN 100% PROTECTED AGAINST MISMATING WITH CODING FINGERS
- Packing Unit: 25 pieces
- Connection Method: CAGE CLAMP® CONNECTION
- Cross Section Solid [mm²]: 0.08 - 1.5 mm²
- Cross Section [mm²]: 0.5-1.5
- Cross Section [AWG]: 28 - 14 AWG
- Strip Length from: 6 mm
- Strip Length to: 7 mm
- No. of Connection Points: 24
- No. of Potentials: 24
- Pole Count: 24
- Height: 13.4 mm
- Height (in): 0.528 in
- Width: 86.2 mm
- Width (in): 3.394 in
- Depth: 18.6 mm
- Depth (in): 0.732 in
- Pin Spacing from: 3.5 mm
- Pin Spacing from (in): 0.138 in
- Pollution Degree: 2
- Measured Voltage EN: 320 V
- Measured Shock Voltage: 2.5 kV
- Current Intensity EN: 10 A
- Material Group: xxx-xxx/035-000
- ABS Approval No.: 04-HG469925/1-PDA
- CCA Approval No.: NL5641
- CSA Approval No.: 154112-1465035
- KEMA Approval No.: 2077592.02
- UR Approval No.: E45171
- UR Approval No. 2: E45172
- Voltage [V]: 250
- Current [A]: 10
