WAGO 734302 2-pole Male Connector
The WAGO 734-302 is a robust 2-pole male connector designed for reliable wire-to-wire and board-to-wire connections. Utilizing WAGO’s innovative CAGE CLAMP® technology, it simplifies cable pre-assembly and on-unit wiring with both vertical and horizontal actuation. The connector’s 100% protection against mismating ensures secure and consistent connections, while the light gray color provides clear visual identification. It is suitable for a wide range of industrial applications requiring dependable power and signal transmission.
WAGO 734302 2-pole Male Connector Specifications:
- Material: Polyamide (PA66)
- Flammability: V0
- Color: light gray
- Rated Voltage (III/3): 160 V
- Rated Surge Voltage (III/3): 2.5 kV
- Rated Current: 10 A
- Conductor Solid: 0.08 … 1.5 mm² / 28 … 14 AWG
- Conductor Fine-Stranded: 0.08 … 1.5 mm² / 28 … 14 AWG
- Conductor Fine-Stranded with Ferrule: 0.25 … 1.5 mm²
- Pin Spacing: 3.5 mm
- Width: 9.4 mm
- Height: 13.4 mm
- Depth: 22.3 mm
- Mismating Protection: Yes
- Pole No.: 2
- Total Connection Points: 2
- Total Potentials: 2
Buy the 734-302 WAGO 2-pole Male Connector | myMectronic
Purchase the WAGO 734-302 male connector securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy WAGO 734302?
You can click on the BUY or RFQ button to purchase 734302 from an authorized WAGO distributor.
How do I troubleshoot issues or seek technical support for part 734302?
You can download the 734302 datasheet or visit the WAGO website for support.
Who is the manufacturer of 734302?
WAGO
