WAGO 739104 4-pole PCB Terminal Block
The WAGO 739-104 is a 4-pole PCB terminal block designed for efficient and reliable connections in various industrial applications. Utilizing the innovative CAGE CLAMP® connection technology, it provides a secure and easy-to-use connection process, eliminating the need for tools. The vertical conductor entry design optimizes space utilization, making it ideal for densely populated PCBs. Rated for 24A and 320V, this terminal block is suitable for a wide range of power distribution and signal transmission applications. It is constructed with durable materials like polyamide (PA66) and chrome nickel spring steel, ensuring long-term performance and reliability.
WAGO 739104 4-pole PCB Terminal Block Specifications:
- Rated Voltage (III/3): 320 V
- Rated Surge Voltage (III/3): 4 kV
- Rated Voltage (III/2): 320 V
- Rated Surge Voltage (III/2): 4 kV
- Rated Voltage (II/2): 630 V
- Rated Surge Voltage (II/2): 4 kV
- Rated Current: 24 A
- Rated Voltage UL (Use Group B): 300 V
- Rated Current UL (Use Group B): 20 A
- Rated Voltage UL (Use Group D): 300 V
- Rated Current UL (Use Group D): 10 A
- Rated Voltage CSA (Use Group B): 300 V
- Rated Current CSA (Use Group B): 12 A
- Rated Voltage CSA (Use Group D): 300 V
- Rated Current CSA (Use Group D): 10 A
- Connection Technology: CAGE CLAMP®
- Solid Conductor Size: 0.08 … 2.5 mm² / 28 … 14 AWG
- Fine-Stranded Conductor Size: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-Stranded Conductor with Ferrule Size: 0.25 … 1.5 mm²
- Fine-Stranded Conductor with Uninsulated Ferrule Size: 0.25 … 2.5 mm²
- Strip Length: 8 … 9 mm / 0.31 … 0.35 inch
- Pin Spacing: 5 mm / 0.197 inch
- Width: 21.5 mm / 0.846 inch
- Height: 19 mm / 0.748 inch
- Height from Surface: 15.8 mm / 0.622 inch
- Depth: 14.3 mm / 0.563 inch
- Solder Pin Length: 3.2 mm
- Solder Pin Dimensions: 0.8 x 1.2 mm
- Drilled Hole Diameter: 1.6 (+0.1) mm
- Material (Insulation): Polyamide (PA66)
- Flammability Class: V0
- Clamping Spring Material: Chrome nickel spring steel
- Contact Material: Electrolytic copper (E) Cu
- Contact Plating: tin-plated
- Fire Load: 0.084 MJ
- Weight: 4.8 g
- Operating Temperature Range: -60 … +105 °C
- Packaging Type: BOX
- Country of Origin: CH
- GTIN: 4044918859509
- Customs Tariff Number: 85369010000
Buy the 739-104 WAGO 4-pole PCB Terminal Block | myMectronic
Purchase the WAGO 739-104 PCB terminal block securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy WAGO 739104?
You can click on the BUY or RFQ button to purchase 739104 from an authorized WAGO distributor.
How do I troubleshoot issues or seek technical support for part 739104?
You can download the 739104 datasheet or visit the WAGO website for support.
Who is the manufacturer of 739104?
WAGO
