WAGO 769109022000 9-pole Female Plug Connector
The WAGO 769-109/022-000 is a 9-pole female plug connector designed for use in electrical distribution systems. It utilizes WAGO’s innovative CAGE CLAMP® connection technology, ensuring a secure and vibration-resistant connection. This connector is suitable for a wide range of applications, including industrial automation, power distribution, and control systems. It is rated for 500V and 32A, making it suitable for demanding environments. The angled design and clear marking options simplify installation and maintenance.
WAGO 769109022000 9-pole Female Plug Connector Specifications:
- Rated voltage (III / 3): 500 V
- Rated impulse voltage (III / 3): 6 kV
- Rated current: 32 A
- Connection technology: CAGE CLAMP®
- Actuation type: Operating tool
- Connectable conductor materials: Copper
- Nominal cross section: 4 mm²
- Solid conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- No. of poles: 9
- Total number of connection points: 9
- Total number of potentials: 9
- Type of wiring: Front-entry wiring
- Width: 45 mm / 1.772 inch
- Height: 37.1 mm / 1.461 inch
- Depth: 26.5 mm / 1.043 inch
- Module width: 5 mm / 0.197 inch
- Contact type (pluggable connector): Female connector/socket
- Connector connection type: for conductors
- Insulating material: Polyamide 66 (PA 66)
- Fire load: 0.395 MJ
- Weight: 23.8 g
- Product Group: 18 (X-COM-System)
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918547659
- Customs Tariff No.: 85366990990
