WAGO 769615 15-Pole Male Connector
The WAGO 769-615 is a robust 15-pole male connector engineered for demanding industrial environments. Utilizing WAGO’s renowned CAGE CLAMP® connection technology, this connector provides a secure and vibration-resistant connection for conductors. It is designed for front-entry wiring and accommodates a wide range of conductor sizes, from 0.08 mm² to 4 mm². The connector’s gray polyamide 66 (PA 66) housing offers excellent insulation and durability. It is commonly used in control cabinets, machinery, and automation systems where reliable power distribution is critical.
WAGO 769615 15-Pole Male Connector Specifications:
- Rated Voltage (III / 3): 500 V
- Rated Impulse Voltage (III / 3): 6 kV
- Rated Current: 32 A
- Connection Technology: CAGE CLAMP®
- Connectable Conductor Materials: Copper
- Nominal Cross Section: 4 mm²
- Solid Conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Fine-Stranded Conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Strip Length: 8 … 9 mm / 0.31 … 0.35 inch
- No. of Poles: 15
- Total Number of Connection Points: 15
- Total Number of Potentials: 15
- Type of Wiring: Front-entry wiring
- Pin Spacing: 5 mm / 0.197 inch
- Width: 78.6 mm / 3.094 inch
- Height: 18.3 mm / 0.72 inch
- Depth: 40.2 mm / 1.583 inch
- Contact Type (Pluggable Connector): Male connector/plug
- Connector Connection Type: for conductors
- Insulating Material: Polyamide 66 (PA 66)
- Fire Load: 0.852 MJ
- Weight: 42.7 g
- Product Group: 18 (X-COM-System)
- Packaging Type: BOX
- Country of Origin: PL
- GTIN: 4044918521888
- Customs Tariff No.: 85366990990
- CCA Approval: DEKRA Certification B.V.
- KEMA/KEUR Approval: DEKRA Certification B.V.
- UL Approvals: UR
