WAGO 788507 115 VAC Relay Module
The WAGO 788-507 relay module is a robust and reliable solution for controlling electrical circuits in industrial automation systems. With a nominal input voltage of 115 VAC and a 1 changeover contact, it provides versatile switching capabilities. The module's limiting continuous current of 16A ensures safe operation under typical load conditions. A red status indicator offers clear visual feedback on the relay's operational state. Reinforced insulation between coil and contacts enhances safety, and the module is designed for DIN-35 rail mounting, facilitating easy integration into control panels. For voltages exceeding 250V, a separator plate is required to maintain reinforced insulation. Inductive loads require effective dampening circuits to protect the relay coils and contacts.
WAGO 788507 115 VAC Relay Module Specifications:
- Nominal input voltage: 115 VAC
- Input voltage range: ±10 %
- Nominal input current at UN: 8 mA
- Number of changeover/switchover contacts: 1
- Contact material (relay): AgNi 90/10
- Limiting continuous current: 16 A
- Max. make current (resistive): (AC) 30 A / 4 s
- Max. switching voltage: AC 250 V
- Max. switching power (resistive): AC 4000 VA
- Switching capacity: AC-15: 6 A / AC 250 V; DC-13: 2 A / DC 24 V
- Recommended minimum load: 12 V / 10 mA
- Pull-in time (typ.): 10 ms
- Drop-out time (typ.): 35 ms
- Bounce time (typ.): 6 ms
- Electrical life (N.O.; resistive load; 23 °C): 30 x 10^6 switching operations
- Mechanical life: 5 x 10^6 switching operations
- Status indication: LED red
- Rated voltage: 250 V
- Rated impulse voltage: 4 kV
- Pollution degree: 3
- Dielectric strength, control/load circuit (AC, 1 min): 5 kVrms
- Dielectric strength open contact (AC, 1 min): 1 kVrms
- Protection class: IP20
- Connection technology: Push-in CAGE CLAMP®
- Solid conductor: 0.34 … 2.5 mm² / 22 … 14 AWG
- Fine-stranded conductor: 0.34 … 2.5 mm² / 22 … 14 AWG
- Strip length: 9 … 10 mm
- Width: 15 mm
- Height from upper-edge of DIN-35 rail: 54 mm
- Depth: 86 mm
- Color: gray
- Fire load: 0.633 MJ
- Weight: 44.9 g
- Standards and specifications: EN 61010-2-201; EN 61810-1; EN 61373; GL; UL 508 (max. 40 °C)
