WEIDMULLER 1001560000 Female Connector
The Weidmuller BLF 5.08HC/05/90 SN OR BX is a versatile female PCB plug-in connector designed for reliable signal transmission in various industrial applications. Featuring an innovative PUSH IN spring connection system, it simplifies wire connection without the need for tools. Its compact design, multiple wire outlet directions, and flange variations provide flexibility for application-specific designs. This connector is suitable for use in automation, control, and power distribution systems where secure and efficient connections are essential.
WEIDMULLER 1001560000 Female Connector Specifications:
- Base Material: PBT
- Color: Orange
- Contact Material: CuSn
- Contact Plating: tinned
- Flammability Rating: V-0
- Insulating Material Group: IIIa
- Operating Temperature Max: 100 °C
- Operating Temperature Min: -50 °C
- Pitch: 5.08 mm
- Push-in Force/Pole: 10 N
- Rated Current Min (Tu=20°C): 24 A
- Rated Current Min (Tu=40°C): 21 A
- Rated Impulse Voltage: 4 kV
- Rated Voltage (CSA Usegroup B): 300 V
- Rated Voltage (CSA Usegroup D): 300 V
- Rated Voltage (IEC): 400 V
- Stripping Length: 10 mm
- Touch-Safe Protection: Yes
- UL Voltage: 300 V
- Wire Connection Cross Section AWG Max: AWG 12
- Wire Connection Cross Section AWG Min: AWG 26
Buy the 1001560000 WEIDMULLER Female Connector | myMectronic
Purchase the Weidmuller BLF 5.08HC/05/90 SN OR BX female connector securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy WEIDMULLER 1001560000?
You can click on the BUY or RFQ button to purchase 1001560000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1001560000?
You can download the 1001560000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1001560000?
WEIDMULLER
