WEIDMULLER 1013520000 Female Connector 10 Pole
The Weidmuller BLF 5.08HC/10/180 SN BK BX is a versatile PCB plug-in connector designed for reliable and efficient connections. Its innovative PUSH IN spring connection system simplifies wire connection, eliminating the need for tools. The connector's compact design, combined with three wire outlet directions, provides flexibility in application design. It is suitable for a wide range of industrial applications requiring robust and easy-to-use connectivity solutions.
WEIDMULLER 1013520000 Female Connector 10 Pole Specifications:
- Type: PCB plug-in connector, female plug
- Number of poles: 10
- Pitch: 5.08 mm
- Connection method: PUSH IN, Spring connection
- Clamping range: max. : 3.31 mm²
- Rated voltage: 400 V / 24 A
- UL voltage: 300 V/18.5 A
- Wire size: 0.2 - 2.5 mm²
- Stripping length: 10 mm
- Material: PBT
- Flammability rating: V-0
- Contact material: CuSn
- Operating temperature: max. 100 °C
- Storage temperature: max. 70 °C
- Touch-safe: Safe from finger touch
- Volume resistance: ≤ 5mΩ
- Plugging force: 7 N
- Pulling force: 5.5 N
- L1: 45.72 mm
- Width: 50.8 mm
- Height: 14.2 mm
- Depth: 27.7 mm
- Net weight: 19.639 g
Buy the 1013520000 WEIDMULLER Female Connector 10 Pole | myMectronic
Purchase the Weidmuller 1013520000 BLF 5.08HC/10/180 SN BK BX securely and efficiently online.
