WEIDMULLER 1059530000 PCB Connector
The OMNIMATE Power series BL/SL 7.62HP is a compact PCB connector designed for UL-600V applications up to 12 kVA, ensuring safety and cost-effectiveness. With a 7.62 mm pitch and 10 poles, it features a THT solder connection, a solder pin length of 3.2 mm, and an insulating material of PBT in black color. It offers touch-safe protection compliant with DIN VDE and UL standards, rated for currents up to 29A at 400V and 20A at 600V, making it suitable for various electrical device applications.
WEIDMULLER 1059530000 PCB Connector Specifications:
- Pitch: 7.62 mm (0.3 inch)
- Number of poles: 10
- Solder pin length: 3.2 mm
- Solder pin dimensions: 1.0x 1.0 mm
- Insulating material: PBT, black color
- UL rating: 300V/20A, 630V/29A
- IEC rating: 630V/29A
- Rated current: 29A at 400V, 20A at 600V
- Operating temperature: -50°C to 100°C
- Creepage distance: 8.1 mm
- Clearance: 6.5 mm
- Contact Material: Copper alloy, nickel and tin plating
- Flammability rating: UL 94 V-0
Buy the Weidmuller Series SL 7.62HP PCB Connector: 1059530000
Purchase the Weidmuller Series SL 7.62HP PCB Connector now to benefit from a high-quality, compact, and touch-safe design rated for UL and IEC standards. With 10 poles, 7.62 mm pitch, and a rated current up to 29A at 400V or 20A at 600V, this connector offers reliable PCB mounting via THT soldering. Its insulating PBT material provides excellent durability and safety, making it suitable for a broad range of electrical applications. Secure your supply chain by buying online today for quick, dependable delivery.
Order your Weidmuller Series SL 7.62HP PCB Connector today and ensure reliable, touch-safe connections for your electrical projects with high-performance quality.
Frequently Asked Questions
Where can I buy WEIDMULLER 1059530000?
You can click on the BUY or RFQ button to purchase 1059530000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1059530000?
You can download the 1059530000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1059530000?
WEIDMULLER
