WEIDMULLER C9039986 Potentiometer Transmitter
The WEIDMULLER picoPak Potentiometer Transmitter is a highly compact and versatile device designed to provide a 2-wire (loop powered) interface for position sensing potentiometers. Its small footprint (6mm wide) makes it ideal for space-constrained applications, while its features like span and zero adjustments, and open wiper detection, ensure accurate and reliable signal conversion. The transmitter is designed to mount on 32mm and 35mm DIN rails, simplifying installation in industrial control panels. It is commonly used in applications requiring precise position feedback, such as automated machinery, process control systems, and robotics.
WEIDMULLER C9039986 Potentiometer Transmitter Specifications:
- Input Range: 0 - 1000 M (minimum)
- Input Impedance: 500k Ω min.
- Field Device Excitation: 1.2 volts, 1.2 mA max.
- Output: 4-20mA (0-100% of input)
- Output Range: 0-500M or Rmax=(Vs-14)/0.02M
- Burnout Level: 4mA (P+ opened), 20mA (P- opened), 23mA (opened wiper)
- Zero Adjustment: minimal, for calibration purposes only
- Span Adjustment: minimal, for calibration purposes only
- Supply Voltage: 19-32Vdc, 24Vdc nominal
- Supply Consumption: 23mA typical (open wiper error detection)
- Accuracy / Linearity: 1% typical over temperature range
- Operating Temperature: -15°C to 55°C
- Storage Temperature: -20°C to 70°C
- Housing: DK5 (TS32 and TS35)
- Dimensions: 78.0 x 6.0 x 60.5 mm
- Wire Range: 22-12AWG (0.5-4.0mm[2])
- Tightening Torque: 0.4Nm
- Insulation Stripping Length: 7mm
