WEIDMULLER 1059570000 PCB Power Connector
The OMNIMATE Power series BL/SL 7.62HP is a PCB plug-in connector designed for low-voltage power applications up to 630V and 29A. It features a compact, single-row, 12-pole male header with 7.62 mm pitch and 90° outlet angle, suitable for UL, IEC, and CSA standards. Made from durable PBT with copper alloy contacts, it provides reliable, touch-safe connections compliant with safety standards. Ideal for device automation, control systems, and power distribution requiring high safety, minimal size, and efficient soldering for PCB assembly.
WEIDMULLER 1059570000 PCB Power Connector Specifications:
- Pitch: 7.62 mm (0.3 inch)
- Number of poles: 12
- Solder pin length: 3.2 mm
- Solder pin dimensions: 1.0 x 1.0 mm
- Solder eyelet hole diameter: 1.3 mm
- Rated voltage IEC: 630 V
- Rated current IEC: 29 A
- Rated voltage UL: 300 V
- Rated current UL: 20 A
- Rated voltage CSA: 300 V
- Rated current CSA: 20 A
- Material: Insulating PBT, contact Copper alloy, silver-tinned surface
- Operating temperature: -50°C to 100°C
- Flammability rating: UL 94 V0
- Insulation resistance: >200 MΩ at 210°C
- Creepage distance: 8.1 mm
- Clearance: 6.5 mm
- Contact protection: Touch-safe according to DIN VDE 0110-5-1
- Cabling: Suitable for AWG 28-12, clamp range 0.08 - 4 mm²
- Connection: THT soldering, plug-in design
- Compliance: UL, IEC, CSA safety standards, RoHS
- Net weight: 6.29 grams
Buy the Weidmueller Series SL 7.62HP PCB Connector: 1059570000
Purchase the Weidmueller Series SL 7.62HP PCB connector online today and experience a compact, high-quality connection solution. Designed for reliable low-voltage power applications, it offers a 12-pole design with a 7.62 mm pitch, suitable for UL, IEC, and CSA standards. Made from durable PBT with copper alloy contacts, it features touch-safe protection, quick soldering, and compliance with safety regulations. Perfect for control panels, automation systems, and power distribution, this connector ensures safety, efficiency, and ease of installation in your projects.
Order your Weidmueller Series SL 7.62HP connector today and ensure reliable, efficient power connections for your industrial or automation projects.
Frequently Asked Questions
Where can I buy WEIDMULLER 1059570000?
You can click on the BUY or RFQ button to purchase 1059570000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1059570000?
You can download the 1059570000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1059570000?
WEIDMULLER
