WEIDMULLER 1059590000 Power Header
High-performance female header designed for UL-600V applications up to 12 kVA, featuring a 7.62mm pitch, no. of poles 3, and a clamping yoke connection. It supports wire sizes from AWG 28 to AWG 12 and offers touch-safe protection per IEC 61140. Made from PBT with a black color, this connector is suitable for applications requiring a rated current of 20A or 29A. It provides a reliable and safe connection with a compact design, meeting both IEC and UL standards for high-voltage device integration.
WEIDMULLER 1059590000 Power Header Specifications:
- Pitch: 7.62 mm (0.3 inch)
- Number of poles: 3
- Connection type: Clamping yoke
- Rated voltage: IEC 630 V, UL 600 V
- Rated current: 29A (IEC), 20A (UL)
- Wire cross-section: AWG 28 to AWG 12
- Clamping range: 0.08 mm² to 4 mm²
- Material: PBT, color: Black, Insulation resistance: 210 MΩ
- Touch-safe protection: Yes, according to DIN VDE 61140
- Creepage distance: Min. 11.3 mm
- Clearance: Min. 9.8 mm
- Rated impulse voltage: 4 kV (IEC), 6 kV (UL)
- Temperature range: -60°C to +100°C
- Flammability rating: UL 94 V-0
- Contact material: Copper alloy, Tinned surface
Buy the Buy Weidmueller Power Header Part Number 1059590000 Online
Secure your power connection with the Weidmueller Power Header, featuring a 7.62mm pitch, 3 poles, UL and IEC compliance, rated for up to 29A or 20A. Designed for durability and safety, it supports wire sizes from AWG 28 to AWG 12 and is made from high-quality PBT material. Perfect for UL 600V applications with touch-safe protection. Its compact form ensures easy integration into devices, reducing size and costs without compromising safety or performance. Purchase online now for quick, dependable delivery.
Order your Weidmueller Series BL/SL 7.62HP Part number 1059590000 today and ensure a safe, reliable, and compact connection solution for high-voltage applications.
Frequently Asked Questions
Where can I buy WEIDMULLER 1059590000?
You can click on the BUY or RFQ button to purchase 1059590000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1059590000?
You can download the 1059590000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1059590000?
WEIDMULLER
