WEIDMULLER 1250410000 PCB terminal
The LSF-SMD 3.50/06/180 SN BK RL is a PCB terminal designed with PUSH IN technology for quick, safe, and reliable wire connections in automated assembly processes. Suitable for both solid and flexible conductors, it features a 3.5mm pitch with 6 poles arranged at 180°. Its insulated body, made from flame-retardant LCP GF, ensures high temperature and moisture resistance, with a rated voltage of 300V and current of 12A per IEC and UL standards. Ideal for industrial electronics, it streamlines assembly with easy wire insertion, detachment, and safe operation, making it an essential component for efficient circuit design.
WEIDMULLER 1250410000 PCB terminal Specifications:
- Pitch: 3.5 mm (0.138 inch)
- Number of Poles: 6
- Pole Arrangement: 180°
- Rated Voltage: 300V (IEC/UL)
- Rated Current: 12A (IEC/UL)
- Clamping Range: 0.13 - 1.5 mm² AWG 24-16
- Material: Flame-retardant LCP GF
- Contact Material: Copper alloy
- Insulation Resistance: 210 MΩ
- Flammability Rating: UL 94 V0
- Operating Temperature: -60°C to 120°C
- Storage Temperature: -25°C to 55°C
- Humidity: Max 80% RH during storage
- Wire End Ferrules: DIN 46228 Pt 1 & 4 compatible
- Compatible with reflow soldering for automated PCB assembly
- Touch-safe protection according to DIN VDE, IP20 rated
Buy the Weidmuller 1250410000 – Reliable PCB Terminal for Industrial Applications
Order the Weidmuller PCB terminal now and enjoy quick, tool-free wire connections with PUSH IN technology. Its robust design, rated for 300V and 12A, ensures safe, reliable performance in automated electronics assembly. Ideal for both solid and flexible conductors, it features a 3.5mm pitch and 6 poles at 180°, making it perfect for efficient circuit design. With high-temperature resistance, UL and IEC certification, and compatibility with reflow soldering, this component simplifies installation, reduces assembly time, and improves circuit durability—all through a seamless online purchase experience.
Buy Weidmuller 1250410000 now and experience unmatched reliability and performance in your electronic circuit assemblies. Perfect for quick wire connection with PUSH IN technology, this component ensures safe, tool-free handling and easy detachment, streamlining manufacturing processes. Its robust design supports automated soldering, making it ideal for high-volume production and maintenance tasks. Enhance your electronics with this top-quality terminal, designed for durability and efficiency, and ensure your projects meet the highest standards of safety and performance.
Frequently Asked Questions
Where can I buy WEIDMULLER 1250410000?
You can click on the BUY or RFQ button to purchase 1250410000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1250410000?
You can download the 1250410000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1250410000?
WEIDMULLER
