WEIDMULLER 1123550000 Solid-State Relay
The product is a versatile solid-state relay designed for efficient load switching in industrial automation systems. It features space-saving 6.4 mm or 12.8 mm modular width, with multiple cross-connection levels for flexible wiring configurations. The relay supports multi-voltage input from 24 to 230 V AC/DC and includes integrated protection and a green status indicator. Its high current capacity of 2A and short-circuit-proof design make it suitable for controlling AC/DC loads up to 250 V. CE, GL, and cULus approved, it ensures reliable performance and easy integration with screw and tension clamp connections, suitable for diverse control applications.
WEIDMULLER 1123550000 Solid-State Relay Specifications:
- Type: Power MOS-FET
- Nominal switching voltage: 3V..83VDC
- Maximum current: 2A
- Voltage drop at max load: 120 mV
- Ambient temperature: -40°C..+60°C
- Storage temperature: -40°C..+85°C
- Humidity: 5..95 % rel. humidity
- Rated voltage: 300V
- Impulse withstand voltage: 6 KV (1.27/50 us)
- Clearance and creepage distance: 25.5 mm
- Surge voltage category: w
- Pollution severity: 2
- Physical dimensions: Length 88 mm, Width 6.4 mm, Height 90 mm (for specific variants)
- Connections: Screw and tension clamp, clamping range 0.14-15 mm
- Compliance: CE, GL, cULus approved
Buy the Buy Weidmuller Solid-State Relay Part Number 1123550000 Online
Order the Weidmuller solid-state relay Part Number 1123550000 online today to ensure your automation system benefits from durable, high-capacity switching. Featuring a compact design of just 6.4 mm width, it supports multi-voltage input from 24V to 230V AC/DC, with a load capacity of 2A. Suitable for diverse industrial applications, it offers integrated protection features, easy wiring with screw and tension clamp connections, and certifications including CE, GL, and cULus. Secure reliable operation for your control systems by purchasing this high-quality relay today.
Get Weidmuller solid-state relay Part Number 1123550000 today—built for reliable load switching in industrial automation with space-saving design and high current capacity.
Frequently Asked Questions
Where can I buy WEIDMULLER 1123550000?
You can click on the BUY or RFQ button to purchase 1123550000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1123550000?
You can download the 1123550000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1123550000?
WEIDMULLER
