WEIDMULLER 1123700000 industrial relay module
The Weidmueller TRZ Series relay module is a versatile, 2-coil, AC/DC/UC control relay designed for industrial automation. It features AgNi contacts with optional gold plating, screw and tension-clamp connections, and protective input circuits including rectifiers. Suitable for control voltages from 24 to 230 V UC, this compact module measures 12.8 mm in width, 90.5 mm in height, and 87.8 mm in depth, and supports resistive loads up to 250 V AC with switching currents of 8 A. Its robust design ensures reliable switching performance under demanding industrial conditions.
WEIDMULLER 1123700000 industrial relay module Specifications:
- Dimensions: Width 12.8 mm, Height 90.5 mm, Depth 87.8 mm
- Control Voltage: 24...230 V UC ±10%
- Rated Control Current: 6 mA @ 230 V UC, 45 mA @ 24 V UC
- Power Rating: 1.08 W @ 24 V UC, 1.38 W @ 230 V UC
- Contact Material: AgNi with optional gold plating
- Number of Contacts: 2 CO (Change Over)
- Rated Switching Voltage: 250 VAC, Max. 250 VAC/DC
- Max Switching Capacity: Resistive load 2000 VA, 192 W @ 24 V
- Mechanical Service Life: 30 million cycles
- Isolation Voltage: 300 V, Surge voltage category: ul 2
- Protection Degree: IP20
- Operating Temperature Range: -40°C to +40°C
- Mounting Type: T-rail (TS 35)
- Connection Method: Tension clamp, stripping length 8 mm
- Wire Range: AWG 26 to AWG 14, Stranded or solid
- Humidity Range: 5% to 95% rel., no condensation
- Standards Compliance: EN 50178, EN 55011, UL Listed (E141197), RoHS
Buy the Weidmueller Series TRZ Relay: 24-230V UC 2CO
Order the Weidmueller TRZ relay module online today to benefit from fast delivery and expert support. This high-quality relay features 2 AgNi contacts, control voltage range of 24 to 230 V UC, and a compact design suitable for automation systems. Its robust construction ensures long-lasting performance under harsh industrial conditions, supporting resistive loads up to 250 V AC with switching currents of 8 A. Perfect for control panels, automation, and switching tasks, this relay guarantees reliability, safety, and ease of installation for your control systems.
Buy Weidmueller TRZ 24-230VUC 2CO relay now and experience unmatched reliability and performance in industrial control applications.
