WEIDMULLER 1147280000 Signal Pin Header
The OMNIMATE Signal series BL/SL 5.08 HC pin headers are made from glass-fibre-reinforced plastic with a 90° wire outlet, optimized for wave soldering. These PCB plug-in male headers feature a closed side, THT solder connection, and an orange insulating body. Designed for 2 poles with a pin length of 3.2 mm, they provide reliable electrical contact with copper-magnesium contacts, layered with Ni/Sn. Suitable for applications requiring high current, these connectors are UL and IEC rated, with robust dimensions and environmental resistance. Easy to mount onto PCBs, they offer coding options and high durability for industrial use.
WEIDMULLER 1147280000 Signal Pin Header Specifications:
- Number of poles: 2
- Pin length: 3.2 mm (+0.17-0.3 mm tolerance)
- Pitch: 5.08 mm (0.2 inch)
- Solder eyelet hole diameter: 1.3 mm
- Material: PA GF (orange)
- Insulation resistance: >10 MΩ
- Operating temperature: -50°C to 100°C
- Rated voltage IEC: 400 V
- Rated current IEC: 24A
- Rated voltage UL: 300 V
- Rated current UL: 18.5 A
- Flammability: UL 94V-0
- Contact material: Copper Mg with Ni/Sn layers
- Dimensions: Height 8.5 mm, depth 12 mm
- Mass: 1.26 g per piece
- Number of solder pins per pole: 1
- Max plugging cycles: 25
- Color: Orange (RAL 2000)
Buy the Weidmueller Series SL 5.08 Signal: 1147280000
Purchase the Weidmueller Series SL 5.08 signal pin headers online now to guarantee high-current, durable connections for your circuit assemblies. These reliable PCB male headers feature a 90° wire outlet, optimized for wave soldering, with UL and IEC approvals for safety and performance. Easy to install, they are constructed from flame-retardant PA GF with copper magnesium contacts layered in Ni/Sn for excellent conductivity and corrosion resistance. Suitable for demanding applications, order now to enhance your electronic and industrial systems with trusted quality.
Order your Weidmueller Series SL 5.08 signal pin headers today and ensure reliable, high-current connections for your industrial projects.
Frequently Asked Questions
Where can I buy WEIDMULLER 1147280000?
You can click on the BUY or RFQ button to purchase 1147280000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1147280000?
You can download the 1147280000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1147280000?
WEIDMULLER
