WEIDMULLER 1234590000 PCB Terminal
The PCB terminal with leaf spring connection features a 5.08 mm pitch, suitable for conductor cross-sections from 0.13 to 2.5 mm² or AWG 26 to 14. It supports a maximum voltage of 600 V (IEC) and 300 V (UL), with rated currents of 24 A and 15 A respectively. Designed for mounting on PCB with THT solder connection, it includes a pressure clamp for secure conductor connection, and features a solder pin length of 3.5 mm, making it ideal for industrial automation and control panels requiring reliable electrical connections.
WEIDMULLER 1234590000 PCB Terminal Specifications:
- Pitch: 5.08 mm (0.2 inch)
- Number of Poles: 7
- Solder pin length: 3.5mm
- Conductor cross-section: 0.13 - 2.5 mm² (AWG 26-14)
- Rated voltage: 600 V (IEC), 300 V (UL)
- Rated current: 24 A (IEC), 15 A (UL)
- Solder eyelet hole diameter: 13mm
- Material: Insulating Wemid (PA), contact copper alloy, tinned
- Temperature range: -60°C to 120°C
- Clamping range: 0.13 mm² to 2.5 mm²
- Tightening torque: 0.4 to 0.5 Nm
- Protection: IP 20, touch-safe according to DIN standards
- Markings: Orange color, RoHS compliant
- Suitable for PCB mounting with THT soldering method
Buy the Buy Weidmueller PCB Terminal Part Number 1234590000 Online
Order the Weidmueller PCB terminal with part number 1234590000 today and ensure secure, reliable electrical connections for industrial automation. Designed for seamless PCB mounting with a 5.08 mm pitch, it supports conductor cross-sections from 0.13 to 2.5 mm² (AWG 26-14) and can handle voltage ratings up to 600 V (IEC) and 300 V (UL). Its pressure clamp system guarantees a firm connection, while the solder pin length of 3.5 mm ensures easy installation. Ideal for control panels, automation systems, and electronic devices, this terminal offers exceptional performance, safety, and longevity.
Get Weidmueller PCB terminal PartNumber 1234590000 today—built for precision, reliable electrical contact, and long-lasting durability in industrial applications.
Frequently Asked Questions
Where can I buy WEIDMULLER 1234590000?
You can click on the BUY or RFQ button to purchase 1234590000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1234590000?
You can download the 1234590000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1234590000?
WEIDMULLER
