WEIDMULLER 2467080000 480W 48V 10A Power Supply
The WEIDMULLER PRO TOP3 480W 48V 10A switch-mode power supply combines high efficiency with a compact housing and exceptional durability. Its direct parallel connection capability eliminates the need for diode modules, leading to cost savings and space optimization within electrical cabinets. The powerful DCL technology ensures smooth operation even with demanding loads like motors, while reliably triggering circuit breakers. Advanced communication capabilities enable permanent condition monitoring and seamless integration with control systems, making it suitable for a wide range of industrial applications.
WEIDMULLER 2467080000 480W 48V 10A Power Supply Specifications:
- Dimensions: Depth: 125 mm, Height: 130 mm, Width: 68 mm, Weight: 1,450 g
- Input Voltage Range: 3 x 320...3 x 575 V AC / 2 x 360...2 x 575 V AC, 450...800 V DC
- Frequency Range: 45…65 Hz
- Rated Input Voltage: 3 x 400...3 x 500 V AC
- Output Power: 480 W
- Output Voltage: 48 V
- Output Voltage Range: 45 V - 56 V
- Output Current: 10 A @ 60 °C
- Peak Load Reserve: 150 % of rated current (Boost duration: 5 s), 500 % (Boost duration: 15 ms)
- Mains Failure Bridge-over Time: > 20 ms @ 115V AC / 230 VAC
- Efficiency: 94%
- Earth Leakage Current: 3.5 mA
- Parallel Connection: Yes, max 10
- Protection: Short-circuit protection, Surge protection (Varistor)
- Operating Temperature: -25 °C...70 °C
- Storage Temperature: -40 °C...85 °C
- EMC Standards: EN 55024, EN 55032, EN 61000-6-1, 2, 3, 4
- Vibration Resistance: 2.3 g (on DIN rail), 4 g (with direct mounting)
- Shock Resistance: 30g in all directions
- Insulation Voltage: 3.5 kV
- Connection System: PUSH IN
- Rated Output Voltage: 48 V DC ± 1 %
- Residual Ripple: < 50 mVss @ UNenn, Full Load
Buy the 2467080000 WEIDMULLER 480W 48V 10A Power Supply | myMectronic
Purchase the WEIDMULLER PRO TOP3 480W 48V 10A power supply securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy WEIDMULLER 2467080000?
You can click on the BUY or RFQ button to purchase 2467080000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 2467080000?
You can download the 2467080000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 2467080000?
WEIDMULLER
