WEIDMULLER 1499760000 Signal Connector
The WEIDMULLER OMNIMATE Signal BL/SL 5.08 BLT 5.08HC/04/180 SN OR BX is a robust and reliable PCB plug-in connector designed for signal transmission in industrial environments. Featuring a TOP connection system, it simplifies wire termination and provides space for labelling. The connector's high-current capability (up to 27A) and robust construction make it suitable for demanding applications. It is ideal for applications requiring a compact and reliable connection solution, such as automation systems, control panels, and power distribution units. The connector is also designed to be touch-safe, enhancing operator safety.
WEIDMULLER 1499760000 Signal Connector Specifications:
- Base Material: PBT
- Color: Orange
- Contact Material: CuSn
- Contact Plating: tinned
- Operating Temperature Max: 100 °C
- Operating Temperature Min: -50 °C
- Storage Temperature Max: 55 °C
- Storage Temperature Min: -25 °C
- Flammability Rating: V-0
- Insulation Resistance: ≥ 108Ω
- Rated Current Min (Tu=20°C): 27 A
- Rated Current Max (Tu=20°C): 19 A
- Rated Current Min (Tu=40°C): 24 A
- Rated Current Max (Tu=40°C): 16 A
- Rated Impulse Voltage: 4 kV
- Rated Voltage: 400 V
- Stripping Length: 13 mm
- Tightening Torque Max: 0.5 Nm
- Tightening Torque Min: 0.4 Nm
- Pitch (mm): 5.08 mm
- Number of Poles: 4
- Connection Type: TOP connection
- Wire Connection Cross Section AWG Min: AWG 26
- Wire Connection Cross Section AWG Max: AWG 14
- Clamping Range Min: 0.13 mm²
- Clamping Range Max: 2.5 mm²
