Weidmuller 1509260000 PCB Connector
The male PCB connector features a 5.08 mm pitch with 14 poles, a 90° outlet and optimized solder pin length of 3.2 mm for wave soldering. Made from orange PBT with nickel and tin-plated copper contacts, it provides a durable, touch-safe, and coding-possible connection suitable for industrial automation. The connector withstands operating temperatures from -50°C to 100°C, rated at 18A current and 400V voltage per IEC standards. It supports up to 25 plugging cycles and complies with safety and UL/CSA standards, ideal for reliable PCB interconnections.
Weidmuller 1509260000 PCB Connector Specifications:
- Pitch: 5.08 mm (0.2 inch)
- Number of poles: 14
- Solder pin length: 3.2 mm (+0.1/-0.3 mm)
- Solder eyelet hole diameter: 1.3 mm (+0.1 mm)
- Pin dimensions: d=1.2 mm, octagonal, Ni/Sn layered surface
- Material: PBT insulating with CuSn contacts
- Rated current: 18A at 20°C, 145A at 40°C
- Rated voltage: 400 V IEC, 300 V UL/CSA
- Temperature range: -50°C to 100°C
- Max. relative humidity: 80%
- Touch-safe protection: IP20, DIN VDE compliant
- Packaging: Box of 50 units
Buy the Weidmueller 1509260000 – Reliable PCB Connector for Industrial Applications
Upgrade your electronic assembly with our reliable PCB connector featuring 14 poles, a 5.08 mm pitch, and optimized solder pin length for industrial applications. Crafted from durable PBT and nickel/tin-plated copper contacts, it offers excellent electrical performance, touch-safe protection, and compatibility with wave soldering processes. Rated for 18A and 400V, it withstands harsh environments from -50°C to 100°C, supporting 25 plugging cycles. Ideal for automation, control panels, and PCB interconnects, ensuring safety and long-term reliability.
Order your Weidmueller Series1509260000 PCB connector today and enhance your industrial projects with dependable, high-quality interconnects suitable for wave soldering.
