WEIDMULLER 1604540000 pin headers
The OMNIMATE Signal series BL/SL 3.50 offers robust pin headers designed for wave soldering with a 3.50 mm pitch, suitable for PCB assembly and high-reliability connections. Featuring a solder connection type, the headers have 9 poles with a solder pin length of 3.2 mm, and a single row configuration. The components are made of flame-retardant PBT material, with tinned copper contacts for durability. These headers support up to 320V and 17A IEC ratings, ensuring safe and reliable performance in automation and electronic modules. With a compact design, they accommodate 1 row, 9 poles, and are available in orange color for easy identification.
WEIDMULLER 1604540000 pin headers Specifications:
- Pitch: 3.5 mm (0.138 inch)
- Number of poles: 9
- Poles per row: 1
- Solder pin length: 3.2 mm (+0.1/-0.3 mm)
- Pin shape: Octagonal, d=1.2 mm
- Solder eyelet hole diameter: 1.4 mm (+0.1 mm)
- Material: PBT, Orange color (RAL 2000), contact material: CuSn, tinned surface
- UL rated: 300V, 10A
- IEC rated: 320V, 17A
- Operating temperature range: -50°C to 100°C
- Storage temperature: -25°C to 55°C, humidity max 80%
- Maximum impulse voltage: 2.5 kV
- Rated current: 10A (UL/CSA), 17A (IEC)
- Contact resistance: 5-7 μm Sn glossy plated surface
- Touch-safe protection: Yes, DIN VDE conform
- Number of solder pins: 9
- Isolation: PBT insulating housing
- Compliance: RoHS, IPC Class 2
- Number of push-in cycles: 25
Buy the Buy Weidmuller OMNIMATE Signal Series BL/SL 3.50 Part Number 1604540000 Online
Purchase the high-quality Weidmuller OMNIMATE Signal pin headers with 3.5mm pitch, 9 poles, and solder connection technology for reliable PCB assembly. These headers are designed for dense electronic modules, rated for 320V and 17A with tinned copper contacts for long-term durability. Suitable for wave soldering processes with a compact, flame-retardant PBT housing in orange, they support multiple soldering cycles, conform to industry standards, and ensure safe, stable electrical connections. Ideal for automation, control panels, and electronic devices—order online today to enhance your manufacturing efficiency.
Get Weidmuller OMNIMATE Signal Series BL/SL 3.50 today—solid for high-reliability PCB connections and wave soldering compatibility.
