WEIDMULLER 1930280000 High-Current PCB Connector
The Weidmüller SV 7.62HP/03/90G 3.5SN BK BX is a high-current PCB male connector designed for robust, reliable connections in industrial applications. Featuring a solder connection type, it has a 7.62 mm pitch with 3 poles, each equipped with durable 3.5 mm tinned pins. The connector supports high electrical ratings, including 1000/630V AC and 57/40.5A, and complies with IEC, UL, and CSA standards. Its compact design includes a black insulating body, solder eyelet holes, and high thermal and mechanical stability, making it ideal for demanding environments.
WEIDMULLER 1930280000 High-Current PCB Connector Specifications:
- Pitch: 7.62 mm (0.3 inch)
- Number of poles: 3
- Solder pin length: 3.5 mm (tolerance +0.1/-0.3 mm)
- Solder eyelet hole diameter: 1.3 mm (tolerance +0.1 mm)
- Pin dimensions: 0.8 x 1.0 mm
- Number of solder pins per pole: 2
- Max. rated voltage: 1000 V AC (IEC), 300V (UL/CSA)
- Max. rated current: 57A (IEC), 40.5A (UL), 5A (CSA)
- Operating temperature range: -60°C to 130°C
- Material: PA GF (black color, RAL 9011), copper alloy contact surface, Ni/Sn plated
- Connection type: THT soldering
- Tinned contact surface: 1-3 μm Ni / 4-6 μm Sn
- Insulation resistance: 210 MΩ
- Flammability rating: UL 94 V0
- Creepage distance: 9.6 mm
- Clearance: 6.9 mm
- Plugging cycles: 25
- Coded for safe connection
Buy the Weidmueller SV 7.62HP – Reliable High-Current Industrial Connector for Industrial Applications
Order the Weidmueller SV 7.62HP high-current PCB connector online now and enjoy reliable performance with a robust design tailored for industrial use. With a pitch of 7.62 mm, 3 poles, and a solder connection type, it offers excellent electrical ratings up to 1000V and 57A, compliant with IEC, UL, and CSA standards. Its durable materials and high thermal stability ensure long-lasting operation in demanding settings. Perfect for industrial automation, control panels, and high-power systems—get yours today for seamless, secure connections.
Get Weidmueller SV 7.62HP today—built for high-current industrial applications and proven durability in demanding environments.
