WEIDMULLER 1930630000 Male Header Connector
High-performance male header designed for side-by-side mounting on PCBs, featuring a patented flange for tool-free fixing and a mating profile that prevents incorrect connections. With a 7.62 mm pitch, 5 poles, and 3.5 mm solder pins, it offers maximum connection reliability and is optimized for lead-free wave soldering. Tinned copper contacts ensure durability, while unique coding and fastening improve installation efficiency—ideal for industrial and automation applications requiring secure, modular connections.
WEIDMULLER 1930630000 Male Header Connector Specifications:
- Pitch in mm (P): 7.62
- Number of poles: 5
- Solder pin length (I): 3.5 mm
- Solder pin dimensions: 0.8x 1.0 mm
- Contact Material: Copper alloy, tin-plated
- Insulating Material: PA GF (Black)
- Rated current, max. (Tu=20°C): 41A
- Rated voltage: 300V (CSA, UL), 630V (IEC)
- Maximum surge voltage class: 6 kV
- Creepage distance: 9.6 mm
- Cabling: THT solder connection, 2 solder pins per pole
- Pin series quantity: 1
- Solder eyelet hole diameter: 1.3 mm
- Operating temperature: -50°C to 130°C
- Flammability rating: UL 94 V0
- Protection class: IP 20
- Touch-safe according to DIN VDE 0570 106
- Max. number of plugging cycles: 25
- Creepage and clearance distances designed per standards
Buy the Buy Weidmiiller SV 7.62HP/05/180G 3.5SN BK BX Online
Order the reliable Weidmiiller male header connector today to ensure secure and efficient PCB connections in your industrial automation systems. Designed with a 7.62 mm pitch, five poles, and 3.5 mm solder pins, it offers durable copper alloy contacts, tin-plated for corrosion resistance. Its tool-less flange fixation and impact-resistant black insulation make installation quick and safe. Supported by UL, IEC, and CSA standards, this high-performance connector guarantees optimal service life and connection integrity across demanding operational environments.
Get Weidmiiller SV 7.62HP/05/180G today—built for precision and long-lasting durability in industrial PCB connections.
Frequently Asked Questions
Where can I buy WEIDMULLER 1930630000?
You can click on the BUY or RFQ button to purchase 1930630000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1930630000?
You can download the 1930630000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1930630000?
WEIDMULLER
