WEIDMULLER 1941100000 PCB Plug-in Connector
The Weidmuller OMNIMATE Signal series BC/SC 3.81 BCZ 3.81/11/180F SN OR BX is a PCB plug-in connector designed for connecting wires with a clamping-yoke screw system. It offers three wire-outlet directions (180°, 90°, and 270°) and various housing shapes, including standard, flange with screw, and flange with a patented release latch. This connector is compatible with customary connector layouts and provides space for labelling and coding, making it suitable for a wide range of industrial applications requiring reliable and flexible connectivity.
WEIDMULLER 1941100000 PCB Plug-in Connector Specifications:
- Base Part No: BC/SC 3.81 BCZ 3.81/11/180F SN OR BX
- Order No: 1941100000
- Version: PCB plug-in connector, female plug, 3.81 mm, No. of poles: 11, 180°, Clamping yoke connection
- GTIN(EAN): 4032248655748
- Quantity: 50pc(s).
- Rated Voltage IEC: 320 V
- Rated Current IEC: 17.5 A
- Conductor Size IEC: 0.2 - 1.5 mm²
- Rated Voltage UL: 300 V
- Rated Current UL: 10 A
- Conductor Size UL: AWG 28 - AWG 16
- Packaging: Box
- Net Weight: 9.391 g
- Pitch (inches): 0.15 inch
- No. of Poles: 11
- L1 (inches): 1.5 inch
- Pin Series Quantity: 1
- Touch-Safe Protection: Safe from finger touch
- Volume Resistance: 6.00 mΩ
- Stripping Length: 7 mm
- Tightening Torque (Screw Flange) Max: 0.3 Nm
- Tightening Torque Max: 0.25 Nm
- Screwdriver Blade: 0.4 x 2.5
- Plugging Cycles: 25
- Material (Insulating): PA GF
- Color: Orange
- Flammability Rating: V-0
- Storage Temperature Min: -25 °C
- Storage Humidity Max: 80 %
- Operating Temperature Max: 120 °C
- Installation Temperature Max: 120 °C
- Clamping Range Min: 0.08 mm²
- Wire Connection Cross Section AWG Min: AWG 28
- Clamping Range Max: 1.5 mm²
- Wire Connection Cross Section AWG Max: AWG 16
