WEIDMULLER 1969570000 Inverted Signal Connector
The SCZ 3.81/05/180G SN OR BX is an inverted pin plug with clamping-yoke screw connection designed for straight wire connections in 3.81 mm pitch. Suitable for wire-to-wire or PCB mating applications, it features space for labeling and coding, with versions including flange options and a tool-free release latch. Rated at 320 V and 17.5 A, it supports flexible and solid wires from AWG 28 to AWG 16. Its compact design ensures secure, reliable connections in industrial and automation systems, complying with safety standards and DIN VDE regulations.
WEIDMULLER 1969570000 Inverted Signal Connector Specifications:
- Dimensions: Pitch in mm 3.81, 5 pole configuration, conductor outlet direction 180°
- Rated Voltage: 320 V (IEC), 300 V (UL), 50 V (CSA)
- Rated Current: 17.5 A (IEC), 10 A (UL & CSA)
- Wire Cross-Section: AWG 28 - AWG 16, solid and flexible
- Clamp Range: 0.08 mm² to 1.5 mm²
- Material: PA GF (Orange), UL 94 V-0
- Insulation Resistance: 210 MΩ
- Temperature Range: -60°C to 120°C
- Protection Class: IP 20, touch-safe protection according to DIN VDE
- Tightening Torque: 0.2 to 0.25 Nm
- Number of Poles: 5, one row
- Locking: Clamping-yoke screw connection, optional release latch
- Certification: IEC 320 V, UL 1059, CSA
- Flammability Rating: V-0
- Storage Temp: -25°C to 55°C, Max Humidity: 80%
Buy the Weidmüller Series BC/SC 3.81 Inverted Pin Plug: 1969570000
Order the Weidmüller BC/SC 3.81 series inverted signal connector online today to ensure high-quality, stable wire-to-wire and PCB connections. Its robust design and safety features, including space for labeling and labelling options, make it ideal for industrial automation. Rated at 320 V and 17.5 A, it supports AWG 28 to AWG 16 wires, offering versatile connection options. The plug’s screw connection ensures secure, strain-relief connections, and the tool-free release latch facilitates easy disconnect. Enhance your automation system with this reliable and compliant connector.
Buy Weidmüller BC/SC 3.81 plug now and experience unmatched reliability and performance in secure wire-to-wire and PCB connections.
Frequently Asked Questions
Where can I buy WEIDMULLER 1969570000?
You can click on the BUY or RFQ button to purchase 1969570000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1969570000?
You can download the 1969570000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1969570000?
WEIDMULLER
