WEIDMULLER 1969590000 Signal Connector
The SCZ 3.81/07/180G SN OR BX is an inverted pin plug designed for straight wire connections in a 3.8 mm pitch, suitable for wire-to-wire and PCB mating. Featuring a clamping-yoke screw connection, it provides space for labelling, is available in four versions, and is compatible with touch-safe protection standards. With a rated current of 17.5A and voltage of 320V IEC, it supports various conductor sizes, offers reliable disconnection, and is ideal for industrial automation and wiring applications. Constructed from orange PA GF and UL V-0 rated, it ensures safety and durability.
WEIDMULLER 1969590000 Signal Connector Specifications:
- Pitch: 3.81 mm (0.15 inch)
- Number of poles: 7
- Rated current: IEC 17.5A, UL 10A
- Rated voltage: IEC 320V, UL 300V
- Clamping range: 0.08 mm to 1.5 mm
- Wire cross-section: AWG 28 to AWG 16
- Material: PA GF (Orange, RAL 2000), UL V-0 rated
- Contact plating: Silver, Sn layer 4-8 μm
- Temperature range: -60°C to 120°C
- Storage temperature: -25°C to 55°C
- Max. humidity: 80%
- Tightening torque: 0.2 to 0.25 Nm
- IP rating: IP20
- UL, CE approvals, conform to IPC, IEC standards
Buy the Weidmueller 1969590000 – Reliable Signal Connectors for Industrial Applications
Get the Weidmueller Signal Connector, model SCZ 3.81/07/180G SN OR BX, readily available online. This 7-pole, 3.81 mm pitch connector offers a secure wire-to-wire and PCB connection, rated for 17.5A and 320V, ideal for automation and industrial wiring. Made from durable UL V-0 rated orange PA GF, it features a clamping-yoke screw, space for labelling, and supports various conductor sizes with a safe, reliable disconnect. Purchase online now for high-quality, easy-to-install wiring solutions that meet international safety standards and ensure continuous operation in demanding environments.
Order your Weidmueller Series SCZ 180° Pin Plug today and ensure robust, secure wiring for your industrial automation and control projects.
