WEIDMULLER 2014400000 Power Terminal
The PCB terminal provides reliable connections for circuits up to 1000V and 76A, suitable for industrial automation and power distribution. It features a 12.7 mm pitch, four poles, and proven clamping yoke connection with a conductor range of 0.5 to 16 mm². Made with tinned copper and enclosed in a black Wemid (PA) insulator, it ensures safety and durability. This component complies with IEC, UL, and CSA standards, making it ideal for robust, high-current applications with easy mounting onto PCBs via solder pins, and offering a 90° conductor outlet.
WEIDMULLER 2014400000 Power Terminal Specifications:
- Number of poles: 4
- Pitch: 12.7mm / 0.5 inch
- Max. conductor cross-section: 16 mm²
- Rated voltage IEC: 1000V
- Rated current IEC: 76A
- Rated voltage UL: 600V
- Rated current UL: 65A
- Solder pin length: 5mm
- Solder pin dimensions: 12x1.2mm
- Solder eyelet hole diameter: 1.6mm ±0.1mm
- Dimensions: Width 49.06mm, Height 36.5mm, Depth 25.1mm
- Material: Insulating Wemid (PA), Contact: tinned copper
- Operating Temp.: -50°C to 120°C
- Flammability: UL 94V-0
- Weather Resistance: IP20 plugged, IP10 unplugged
- Clamping range: 0.5 mm² to 16 mm²
- Conductor types: solid, stranded, flexible
- Tightening torque: 1.2–1.5 Nm
- Suitable for PCB mounting via THT soldering
- Compliance: IEC 60664-1, IEC 61984, UL 600V, CSA 600V
- Additional: RoHS compliant
Buy the Weidmueller LUP 12.70/04/90 5.0SN – Reliable PCB Power Terminal for Industrial Applications
Secure your power connections with the Weidmueller Power Terminal. Designed for high voltage circuits, it features a 12.7 mm pitch, 4 poles, and a proven clamping yoke connection. Made with durable, flammable-rated materials, it ensures safety and long-lasting performance. Ideal for power distribution and automation control panels, this terminal supports conductor sizes from 0.5 to 16 mm², with easy PCB mounting via solder pins. Ensure reliable, high-current connections today for efficient industrial operations.
Buy Weidmueller LUP 12.70/04/90 5.0SN now and experience unmatched reliability and performance in power and automation systems.
