WEIDMULLER 2014590000 PCB Terminal
The PCB terminal provides reliable connections for 1000 V and 76 A with a 16 mm cross-section capacity. Designed with proven clamping yoke connection at a 12.7 mm pitch and a 90° conductor outlet, it features solder pins of 5 mm length, black tin-plated contact surfaces, and a compact box packaging. Suitable for PCB mounting via THT solder connection, it ensures safe, durable, and high-performance electrical connections for industrial and electrical applications, complying with UL, IEC, and CSA standards for voltage and current ratings.
WEIDMULLER 2014590000 PCB Terminal Specifications:
- Rated voltage: 1000 V / 600 V (UL/IEC)
- Rated current: 76 A / 65 A (UL/IEC)
- Number of poles: 6
- Pitch: 12.7 mm
- Solder pin length: 5 mm
- Solder pin dimensions: 12 x 1.2 mm
- Solder eyelet hole diameter: 1.6 mm (tolerance +0.1 mm)
- Max. clamping range: 16 mm
- Wire cross-section: AWG 22 - AWG 6
- Clamping range: 0.13 mm² - 16 mm²
- Material: Wemid (PA), black, UL 94 V0
- Contact material: Tin-plated copper
- Dimensions: Width 74.46 mm, Height 36.5 mm, Depth 25.1 mm
- Weight: 60.92 g
- Operating temperature: -50°C to 120°C
- Storage temperature: -40°C to 70°C
- Touch-safe protection: IP20 plugged, IP10 unplugged
- Certification: UL, IEC, CSA
Buy the Weidmueller LUP 12.70/06/90 5.0SN BK BX – Reliable PCB Terminal for Industrial Applications
Secure your electrical connections efficiently with this high-quality PCB terminal. Designed for 1000 V and 76 A, it features a robust clamping yoke connection, 12.7 mm pitch, and compatibility with AWG 22 to AWG 6 wire sizes. Easy to install on PCB via THT soldering, its compact black design ensures durability and safety in industrial settings. Ideal for professionals seeking reliable and standards-compliant connectors for complex electrical systems. Order now online for fast, trusted delivery and seamless integration into your projects.
Buy Weidmueller LUP 12.70/06/90 5.0SN BK BX now and experience unmatched reliability and high-performance electrical connections for industrial use.
Frequently Asked Questions
Where can I buy WEIDMULLER 2014590000?
You can click on the BUY or RFQ button to purchase 2014590000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 2014590000?
You can download the 2014590000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 2014590000?
WEIDMULLER
