WEIDMULLER 2014610000 PCB Terminal
The PCB terminal provides reliable connections for 1000 V, 76 A, and wire cross-sections from 0.5 mm² to 16 mm², featuring proven clamping yoke technology at a 12.7 mm pitch and a 90° conductor outlet. Its compact design includes seven poles, solder pins of 5 mm length, and insulated with durable tinned copper surfaces. Suitable for PCB mounting via THT soldering, it meets IEC, UL, and CSA standards for high voltage and current applications, with a black Wemid insulating shell for enhanced safety and durability in industrial environments.
WEIDMULLER 2014610000 PCB Terminal Specifications:
- Pitch: 12.7 mm
- Number of poles: 7
- Solder pin length: 5 mm
- Maximum conductor cross-section: 16 mm²
- Wire range: 0.5-16 mm²
- Rated voltage IEC: 1000 V
- Rated current IEC: 76 A
- Rated voltage UL: 600 V
- Rated current UL: 65 A
- Solder eyelet hole diameter: 1.6 mm
- Solder pin dimensions: 12 x 1.2 mm
- Dimensions: Width 87.16 mm, Height 36.5 mm, Depth 25.1 mm
- Material: Wemid (PA), insulated, black, UL94 V0
- Contact material: Tinned copper (ECu)
- Flammability rating: UL 94 V0
- Temperature range: Operating -50°C to +120°C
- Tinning layer: 1.5–3 μm Ni / 4–6 μm Sn
- Certification: IEC, UL, CSA approved
Buy the Weidmueller Series LUP PCB Terminal: 2014610000
Order the Weidmueller PCB Terminal LUP 12.70/07/90 5.0SN BK BX online today for reliable high-voltage connections. This 7-pole terminal supports wire cross-sections from 0.5 mm² to 16 mm² and features proven clamping yoke technology at a 12.7 mm pitch. Its durable insulative shell ensures safety in demanding environments. Perfect for industrial automation and electrical wiring, this terminal meets IEC, UL, and CSA standards, providing long-term performance and easy PCB mounting for professional applications.
Get Weidmueller LUP 12.70/07/90 5.0SN BK BX today—built for precision and long-lasting durability.
Frequently Asked Questions
Where can I buy WEIDMULLER 2014610000?
You can click on the BUY or RFQ button to purchase 2014610000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 2014610000?
You can download the 2014610000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 2014610000?
WEIDMULLER
